Shantui SD16F Bulldozer for Sale
- Qingdao port china
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | SHANTUI Bulldozer | |
| Model Number | SD16F bulldozer | Condition | New | |
| Moving Type | Wheel Bulldozer | Machine Weight | 17T | |
| Dimension(Long * Breadth * High) | 5140*3388*3032mm | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Shantui 160HP bulldozer SD16F bulldozer
Features of Shantui SD16F bulldozer
The SD16F forest bulldozer has been developed for operation in forests. The SD16F is equipped with a hydraulic drive system with hydraulic control technology, a front-extending ROPS canopy, and an advanced structure, providing reliable performance and convenient and flexible operation, and easily adapting it to operations in the forest.
Specification of Shantui SD16F bulldozer
ITEM | UNIT | SD16F |
L×W×H (Ripper not included) | mm | 5345*3388*3032 |
Operating weight (Ripper not included) | t | 17.5 |
Engine | - | Shangchai SC11CB184G2B1/ Weichai WD10G178E25 |
Rated power | kW/rpm | 120/1850 |
Gradeability | ° | 30 |
Blade type | - | Straight tilt blade U blade Angle blade |
Blade width | mm | Straight tilt blade 3388×1149 U blade 3556×1120 Angle blade 3970×1040 |
Dozing capacity | m3 | Straight tilt blade 4.5 U blade 5 Angle blade 4.3 |
Ma× drop below ground of blade | mm | 540 |
Lift height of blade | mm | 1095 |
Ripper type | - | Three-shank ripper |
Ripping depth of ripper | mm | 572 |
Lifting height of ripper | mm | 592 |
Number of carriers (each side) | - | 2 |
Number of track rollers (each side) | - | 7 |
Number of track shoes (each side) | - | 39 |
Width of track shoe | mm | 560 |
Track gauge | mm | 1880 |
Ground length and ground pressure | mm/MPa | 2635-0.062 |
Pitch | mm | 203.2 |
Forward speed | km/h | 0–3.29 |
0–5.82 | ||
0–9.63 | ||
Reverse speed | km/h | 0–4.28 |
0–7.59 |
For more information about our Shantui SD16F bulldozer, pls feel free to contact us
