36KW~72KW Silent Type Diesel Welding Generator Set (36KW~72KW)

FOB Price

Negotiable / Set

4 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1) It is very convinient to use
2) It can just be used as a generator ,also can be used as a welder

Genset Model	50HZ Power factor: 0.8 400/230V Three phase and four wire			Fuel consumption	Engine Model	CUMMINS diesel engine(1500/rpm)	The dimension	Weight
	Rated power			Diesel			L×W×H	Weight
	KVA	KW	A	L/H		KW	mm	kg
JDP-C50	45	36	65	9	4BTA3.9-G	55	1730×700×1150	1070
JDP-C70	63	50	90	11.3	4BTA3.9-G	55	1730×700×1150	1070
JDP-C100	90	72	130	16.2	6BT5.9-G	100	2180×820×1347	1200
JDP-C110	100	80	135	18	6BT5.9-G	100	2180×820×1347	1200
JDP-C138	125	100	180	24	6BTAA5.9-G	132	2300×820×1340	1400
JDP-C163	150	120	216	28.8	6BTAA5.9-G	132	2300×820×1340	1400
JDP-C203	188	150	270	40	6CA8.3G2	180	2450×860×1430	1600
JDP-C225	200	160	288	45	6CTAA8.3G	200	2560×880×1150	1700
JDP-C275	250	200	360	48	NTA855-G1	265	2850×970×1580	3100
JDP-C275	222	200	361	48	NT855-GA	250	2850×970×1580	3100
JDP-C313	275	220	396	52.8	NTA855-G1A	290	2950×970×1580	3100
JDP-C350	313	250	450	60	NTA855-G2	321	2950×970×1580	3250
JDP-C388	350	280	504	76	NTA855-G4	351	3300×970×1650	2950
JDP-C388	350	280	504	76	NTA855-G2A	351	3300×970×1650	3250
JDP-C413	375	300	540	83	NTAA855-G7	377	3370×1340×1650	3750
JDP-C413	375	300	540	83	KTA19-G2	369	3370×1230×1920	4350
JDP-C500	450	360	648	97	KTA19-G3	448	3410×1230×1920	4800
JDP-C550	500	400	720	107	KTA19-G4	504	3475×1230×1920	4800
JDP-C600	550	440	792	118	KTAA19-G5	555	3490×1920×2379	4800
JDP-C625	563	450	810	118	KTAA19-G6	570	3490×1920×2379	4800
JDP-C688	625	500	900	142	KTAA19-G7	620	3590×1920×2379	4800
JDP-C750	688	550	990	156	KT38-GA	660	4240×1630×2250	8950
JDP-C825	750	600	1080	167	KTA38-G2	731	4240×1630×2250	9650
JDP-C900	800	640	1152	178	KTA38-G2A	893	4240×1630×2250	9650
JDP-C1000	850	720	1296	185	KTA38-G2A	893	4240×1630×2250	8950
