Product Details

Condition	New	Type	Evaporative Air Cooler
Place of Origin	Fujian, China	Brand Name	Aolan
Model Number	AJL90-FH150A	Operating Voltage	Other, 220V
Mounting	Floor Standing	Certification	Other
After-sales Service Provided	No overseas service provided

Product Description

Indirect Industry air cooler without humidity added for computer room

Model:AJL90-FH150A

Means serial No. A dew point indirect evaporative air cooler units with nominal cooling capacity 90kw,nominal airflow15000m3/h,structure type:combined

Marks:standard working conditions for cooling performance

dry bulb temperature 38 °C

Wet bulb temperature 23°C

Working Principle

Fresh air is divided into many small flows which pass the dry channels in the cooling core.Every small flow is cooled by all the small flows before it crossing pass in another side channels called wet channels. Dry and wet channels are placed one by one with thinner wall separately made of special materials.Heat transfers but no water exchanges.Flows are coolde down but no moisture added.Then every flow goes into wet channels placed its two sides by through its controlling holes,contact with the counter-flow water.It is cooled and little moisture added.Bring the heat out passed from its two-side.Its temperature is lowed down continuously,at the end;its temperature goes under the wet-bulb of its beginning flow,near the dew-point temperature.

Features

1) High efficiency,COP reach to over 40
2) System can work well in 50°C environment,and ambient temperature rise,cooling ability increase
3) Wet-bulb efficiency over 120%
4) Easy maintenance
5) Auto-control
6) Environment friendly
7) Patented,high tech method of self-cooled multi-stage indirect evaporative cooling

Dimension Drawing

Air Supply Rate(m3/h)	15000	Water Consumption(l/h)	90
Fresh Air Cooling Capacity(Kw)	90	Dimension Drawing (mm)	251017102425
Air Outlet Residual pressure (Pa)	150	Net Weight(Kg)	950
Power Resource(V/Hz)	380/50	Noise bB(A)	75
Input Power(Kw)	3.3	Supply Air(mm)	850*380
COP(Kw/Kw)	27	Exhaust Air(mm)	7301304
Wet Bulb Efficiency(%)	120	Function	Cooling& Humidifying
Run Current(A)	9.5	Motor Speed	3-phase,2-speed
Fresh Air Rate(%)	100	Controller Type	2012 LCD Control

Application Filed
