Stainless Steel Rotary Type Pill Press for Sale
- China Port
- T/T Credit Card
You May Like
-
Tablet Press Compression Machine That Make Pills Price
-
Mini Samll Medicine Tablet Making Press Machine
-
Automatic Small Effervescent Pill Tablet Press Machine
-
Single Punch Calcium Vatop Tablet Press Machine
-
Little Type Single Punch Calcium Tablet Press Machine
-
Low Price Single Punch Candy Pill Press Machine for Sale
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | MG | Model Number | MG | |
| Type | Rotary Tablet Press | Production Capacity | 130000 PCs/h | |
| Max. Pressure(KN) | 80 | Max. Tablet Thickness(mm) | 6mm | |
| Max. Tablet Diameter(mm) | 20mm | Voltage | 380V | |
| Power(W) | 3KW | Weight | 2100Kg | |
| Dimension(L*W*H) | 1100*1160*1700mm | Certification | ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Stainless steel Rotary type pill press for sale
Application:
This machine is a double pressing type, continuous automatic tablet press for pressing granular raw materials into tablets. It is mainly used in pharmaceutical industry and also the chemical, food, electric industries.
Structural Features:
1.The machine designed for fully enclosed structure; It has the advantage of good appearance in design, high efficiency, lower energy consumption and etc.
2. The material contact parts is made of stainless steel, the surface of turntable deal with polished to prevent cross pollution which meet the GMP requirements.
3. It's equipped with plexiglass perspective window for tablet producing observation and maintenance.
4. Driving system is equipped with oil box and running under oil, easy for heat dissipation and durable, non-pollution.
5. It adopts import frequency timing, with hydraulic system.
6. with the over-loading protection.
Technical Parameters:
Type | MG-31 | MG-35 | MG-39 |
Die Amount | 31staions | 35staions | 39staions |
Max. pressure | 80KN | 80KN | 80KN |
Max. Filling Depth | 15mm | 15mm | 15mm |
Max. Diameter | Φ20 mm | Φ13 mm | Φ13 mm |
Max. tablet Thickness | 6mm | 6mm | 6mm |
Speed(r/min) | 14-36 | 14-36 | 14-36 |
Capacity (PCs/h) | 130000 | 150000 | 170000 |
Power supply | 4KW380V50HZ | 4KW380V50HZ | 4KW380V50HZ |
Overall Dimension(mm) | 1100*1160*1700 | 1100*1160*1700 | 1100*1160*1700 |
Weight | 2100Kg | 2100Kg | 2100Kg |
