Home > Products > Split & Sliding Bearing > high quality SN318 steel bearing housing
high quality SN318 steel bearing housing
USD $0.1 - $150
/ Piece
100 Pieces(Min.Order)
- Shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
| Brand Name | HHZC | Precision Rating | ABEC-1 | |
| Model Number | SN318 | Place of Origin | Jiangsu, China |
Product Description
Specifications
1.high quality SN318 pillow block bearing2.material:cast-iron
3.packing:single box
4:competitive price
5.OEM service
The main products of our company is Plummer blocks, such as SN series , SD series , SNU series , Z2500Y series…;plain bearing block housings, such as H2000 series , H4000 series , ZHC2-00 series , XH000 series…;Insert ball bearing units, such as UCP series , UCF series , UCFL series , UCT series; Adapter sleeves, withdrawal sleeves and other bearing accessories. Besides, we also can offer OEM service, or process non-standard bearing housings according to the customers' samples or drawings.
Product picture:
Product Date Sheet:
| Housing No. | Shaft dia (mm) | Dimensions(mm) | Housing Wt (kg) | Bearing No. | Locating Ring | |||||||||||||||||
| d | d1 | D H8 | a | b | c | g H12 | h h12 | L | W | m | u | v | f1 H12 | f2 | d2 H12 | d3 H12 | Number | QTY | ||||
| SN305 | 25 | 30 | 62 | 185 | 52 | 22 | 34 | 50 | 80 | 90 | 150 | 15 | 20 | 31.5 | 43 | 4 | 5.4 | 1.6 | 1305 2305 | SR62x8.5 SR62x10 | 2 1 | |
| SN306 | 30 | 35 | 72 | 185 | 52 | 22 | 37 | 50 | 82 | 95 | 150 | 15 | 20 | 36.5 | 48 | 4 | 5.4 | 1.9 | 1306 2306 | SR72x9 SR72x10 | 2 1 | |
| SN307 | 35 | 45 | 80 | 205 | 60 | 25 | 41 | 60 | 90 | 110 | 170 | 15 | 20 | 46.5 | 58 | 4 | 5.4 | 2.6 | 1307 2307 | SR80x10 SR80x10 | 2 1 | |
| SN308 | 40 | 50 | 90 | 205 | 60 | 25 | 43 | 60 | 95 | 115 | 170 | 15 | 20 | 51.5 | 67 | 5 | 6.9 | 3.2 | 1308 2308 | 21308 22308 | SR90x10 SR90x10 | 2 1 |
| SN309 | 45 | 55 | 100 | 255 | 70 | 28 | 46 | 70 | 105 | 130 | 210 | 18 | 23 | 56.5 | 72 | 5 | 6.9 | 4.5 | 1309 2309 | 21309 22309 | SR100x10.5 SR100x10 | 2 1 |
| SN310 | 50 | 60 | 110 | 255 | 70 | 30 | 50 | 70 | 115 | 135 | 210 | 18 | 23 | 62 | 77 | 5 | 6.8 | 5.0 | 1310 2310 | 21310 22310 | SR110x11.5 SR110x10 | 2 1 |
| SN311 | 55 | 65 | 120 | 275 | 80 | 30 | 53 | 80 | 120 | 150 | 230 | 18 | 23 | 67 | 82 | 5 | 6.8 | 6.6 | 1311 2311 | 21311 22311 | SR120x12 SR120x10 | 2 1 |
| SN312 | 60 | 70 | 130 | 280 | 80 | 30 | 56 | 80 | 125 | 155 | 230 | 18 | 23 | 72 | 89 | 6 | 8.1 | 7.0 | 1312 2312 | 21312 22312 | SR130x12.5 SR130x10 | 2 1 |
| SN313 | 65 | 75 | 140 | 315 | 90 | 32 | 58 | 95 | 130 | 175 | 260 | 22 | 27 | 77 | 94 | 6 | 8.1 | 8.8 | 1313 2313 | 21313 22313 | SR140x12.5 SR140x10 | 2 1 |
| SN314 | 70 | 80 | 150 | 320 | 90 | 32 | 61 | 95 | 130 | 185 | 260 | 22 | 27 | 82 | 99 | 6 | 8.1 | 10.3 | 1314 2314 | 21314 22314 | SR150x13 SR150x10 | 2 1 |
| SN315 | 75 | 85 | 160 | 345 | 100 | 35 | 65 | 100 | 140 | 195 | 290 | 22 | 27 | 87 | 104 | 6 | 8.1 | 11.4 | 1315 2315 | 21315 22315 | SR160x14 SR160x10 | 2 1 |
| SN316 | 80 | 90 | 170 | 345 | 100 | 35 | 68 | 112 | 145 | 212 | 290 | 22 | 27 | 92 | 111 | 7 | 9.3 | 13.0 | 1316 2316 | 21316 22316 | SR170x14.5 SR170x10 | 2 1 |
| SN317 | 85 | 95 | 180 | 380 | 110 | 40 | 70 | 112 | 155 | 218 | 320 | 26 | 32 | 97 | 116 | 7 | 9.3 | 16.0 | 1317 2317 | 21317 22317 | SR180x14.5 SR180x10 | 2 1 |
| SN318 | 90 | 100 | 190 | 400 | 110 | 33 | 74 | 112 | 160 | 230 | 320 | 26 | 35 | 102 | 125 | 8 | 10.8 | 22.8 | 1318 2318 | 21318 22318 | SR190x15.5 SR190x10 | 2 1 |
| SN319 | 95 | 110 | 200 | 420 | 120 | 36 | 77 | 125 | 170 | 245 | 350 | 26 | 35 | 113 | 135 | 8 | 10.7 | 27.8 | 1319 2319 | 21319 22319 | SR200x16 SR200x10 | 2 1 |
| SN320 | 100 | 115 | 215 | 420 | 120 | 38 | 83 | 140 | 175 | 280 | 350 | 26 | 35 | 118 | 140 | 8 | 10.7 | 34.0 | 1320 2320 | 21320 22320 | SR215x18 SR215x10 | 2 1 |
| SN322 | 110 | 125 | 240 | 460 | 130 | 40 | 90 | 150 | 190 | 300 | 390 | 28 | 38 | 128 | 154 | 9 | 12.2 | 45.0 | 1322 2322 | 21322 22322 | SR240x20 SR240x10 | 2 1 |
| SN324 | 120 | 135 | 260 | 540 | 160 | 50 | 96 | 160 | 205 | 325 | 450 | 33 | 42 | 138 | 164 | 9 | 12.2 | 62.0 | 22324 | SR260x10 | 1 | |
| SN326 | 130 | 150 | 280 | 560 | 160 | 50 | 103 | 170 | 215 | 350 | 470 | 33 | 42 | 153 | 183 | 10 | 13.7 | 68.8 | 22326 | SR280x10 | 1 | |
| SN328 | 140 | 160 | 300 | 630 | 170 | 55 | 112 | 180 | 235 | 375 | 520 | 35 | 45 | 163 | 193 | 10 | 13.7 | 98.0 | 22328 | SR300x10 | 1 | |
| SN330 | 150 | 170 | 320 | 680 | 180 | 55 | 118 | 190 | 245 | 395 | 560 | 35 | 45 | 173 | 203 | 10 | 13.7 | 116.0 | 22330 | SR320x10 | 1 | |
| SN332 | 160 | 180 | 340 | 710 | 190 | 60 | 124 | 200 | 255 | 415 | 580 | 42 | 52 | 183 | 213 | 10 | 13.7 | 135.0 | 22332 | SR340x10 | 1 | |
Work Shop:
Canton Fair Show:
Contact Us
- Nantong Haihui Bearing Co., Ltd.
- Contact nameGeorge Huang Chat Now
- Phone86-513-82227209
- AddressNo.52 Daqian Building 5, Nantong Haimen, Nantong, Jiangsu
