Vibration Separator for Avoiding Material Get Together
- Shanghai port
- T/T D/P D/A Credit Card
You May Like
-
China High Efficient Rotary Vibration Screen Filter
-
HY CE Certificate Linear Vibration Sieve Machine for Powder
-
China Rotary Vibration Filter Sieve for Powder Coating
-
Aluminum Powder Sieving Machine Made in China
-
China Common Steel Mechanical Soil Sieve Equipment
-
China Good Performance Sawdust Screening Machine
Product Details
| Place of Origin | Henan, China | Brand Name | HENG SHUN | |
| Model Number | HY-600-1S | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
It is a good helper For Grading, Screening and separating
HY series vibration separator for sorting automatically powders and solid material in general. Six years of modifications and technical up-dates, the wide range available, the accessories and the tested effectiveness and reliability make the machine is well received in home and aboard.
Function as follows:
A. Classification
Each of our vibrating separator and separate precisely and continuously, the Multi—layer type can screen and separate five groups of different particles at a time. It is suitable for dry materials.
B. Filtration
The mixture of solid and liquid can be separated effectively by single or multi—layer type into different grade materials.
C. Remove the impurities
Our vibration separator can quickly separate a few oversize or undersize particles from a quantity of materials.

Construction features
* Clamping system by rings
* All parts in contact with the product are made of stainless steel 304.
* Base mad of common steel or stainless steel, as customer’s requirement.
* Discharge outlet with sloped bottom
* Electrical motor vibrator, IP65 insulation.
Advantages
- Precise screening thanks to square-mesh nets
- Fast waste discharge
- High reliability thanks to its resistant structure
- Low noise
- Easy to maintain
Technical Parameters
Model | Power(kw) | Effective Diameter | Dimensions(mm) | Layer/ Deck | |
HY -400 | 1S | 0.18 | 360 mm | 580x580x560 | 1 |
2S | 580x580x670 | 2 | |||
3S | 580x580x780 | 3 | |||
HY -600 | 1S | 0.25-0.55 | 560 mm | 800x800x750 | 1 |
2S | 800x800x890 | 2 | |||
3S | 800x800x1030 | 3 | |||
HY -800 | 1S | 0.55-0.75 | 760 mm | 900x900x750 | 1 |
2S | 900x900x890 | 2 | |||
3S | 900x900x1030 | 3 | |||
HY -1000 | 1S | 0.75-1.5 | 930 mm | 1160x1160x810 | 1 |
2S | 1160x1160x950 | 2 | |||
3S | 1160x1160x1090 | 3 | |||
HY -1200 | 1S | 1.10-1.75 | 1130 mm | 1360x1360x885 | 1 |
2S | 1360x1360x1050 | 2 | |||
3S | 1360x1360x1275 | 3 | |||
HY -1500 | 1S | 1.50-2.20 | 1430 mm | 1850x1850x990 | 1 |
2S | 1850x1850x1185 | 2 | |||
3S | 1850x1850x1380 | 3 | |||
HY-1800 | 1S | 2.20-3.0 | 1730 mm | 2200x2200x1050 | 1 |
2S | 2200x2200x1250 | 2 | |||
3S | 2200x2200x1450 | 3 | |||
Note: The above mentioned model is our standard model and we also can make some changes according to your working site or special demands, contact us today````
You can choose the models with two ways:
Quality Assurance
a. Experienced staff
b. Quality Control Department
c. Third-party supervision
Our products passed the ISO9001:2008 and CE certification
