OFF LOAD TAP CHANGER
- 100000 Piece / Pieces per Month
- XINGANG PORT
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Tianjin, China | Brand Name | ENC | |
| Model Number | 1P or 3P |
Product Description
Specifications
1 Off load tap changer (one phase or three phases)2 Applies to oil-immersed power transformers
3 Knot material: Aluminum
OFF LOAD TAP CHANGER FOR TRANSFORMER
This kind of switch applies to the single-phase three phase combination oil-immersed transformer of electrical power with frequency of 50HZ 60HZ rated voltage of 10KV 35KV rated current of 63A 125A 250A the voltage-regulating places are central part neutral point can be directly fixed on the box-cover of the transformer under the non-excitation condition regulating and changing.
1) the tapchanger of 63A applies to box-cover of the transformer of 5~8mm;
2) the tapchanger of 125A applies to box-cover of the transformer of 6~10mm;
3) the tapchanger of 250A applies to box-cover of the transformer of 8~12mm;
Type Of Tap Changer | Reted Current A | Rated Voltage KV | VoltageRegulating Place |
WSPII63/10-4×3 | 63 | 10 | Central |
WSPII125/10-4×3 | 125 | 10 | Central |
WSPII250/10-4×3 | 250 | 10 | Central |
WSPII63/35-4×3 | 63 | 35 | Central |
WSPII125/35-4×3 | 125 | 35 | Central |
WSPII250/35-4×3 | 250 | 35 | Central |
WSPII63/10-6×5 | 63 | 10 | Central |
WSPII125/10-6×5 | 125 | 10 | Central |
WSPII250/10-6×5 | 250 | 10 | Central |
WSPII63/35-6×5 | 63 | 35 | Central |
WSPII125/35-6×5 | 125 | 35 | Central |
WSPII250/35-6×5 | 250 | 35 | Central |
WSPII63/10-8×7 | 63 | 10 | Central |
WSPII125/10-8×7 | 125 | 10 | Central |
WSPII250/10-8×7 | 250 | 10 | Central |
WSPII63/35-8×7 | 63 | 35 | Central |
WSPII125/35-8×7 | 125 | 35 | Central |
WSPII250/35-8×7 | 250 | 35 | Central |
WSTI63/10-3×3 | 63 | 10 | End section |
WSTI125/10-3×3 | 125 | 10 | End section |
WSTI250/10-3×3 | 250 | 10 | End section |
WSTI63/10-5×5 | 63 | 10 | End section |
WSTI63/10-5×5 | 125 | 10 | End section |
WSTI63/10-5×5 | 250 | 10 | End section |
WSPII63/10-4×3 | 63 | 10 | Central |
WSPII125/10-4×3 | 125 | 10 | Central |
WSPII250/10-4×3 | 250 | 10 | Central |
WSPII63/35-4×3 | 63 | 35 | Central |
WSPII125/35-4×3 | 125 | 35 | Central |
WSPII250/35-4×3 | 250 | 35 | Central |
WSPII63/10-6×5 | 63 | 10 | Central |
WSPII125/10-6×5 | 125 | 10 | Central |
WSPII250/10-6×5 | 250 | 10 | Central |
WSPII63/35-6×5 | 63 | 35 | Central |
WSPII125/35-6×5 | 125 | 35 | Central |
WSPII250/35-6×5 | 250 | 35 | Central |
WSPII63/10-8×7 | 63 | 10 | Central |
WSPII125/10-8×7 | 125 | 10 | Central |
WSPII250/10-8×7 | 250 | 10 | Central |
WSPII63/35-8×7 | 63 | 35 | Central |
WSPII125/35-8×7 | 125 | 35 | Central |
WSPII250/35-8×7 | 250 | 35 | Central |
WSTII125/10-3×2 | 125 | 10 | Central |
WSTII250/10-3×2 | 250 | 10 | Central |
WSTII125/10-3×2 | 125 | 10 | Central |
WSTII250/10-3×2 | 250 | 10 | Central |
WSTII63/10-4×3 | 63 | 10 | Central |
WSTII125/10-4×3 | 125 | 10 | Central |
WSTII250/10-4×3 | 250 | 10 | Central |
WSTII63/10-6×5 | 63 | 10 | Central |
WSTII125/10-6×5 | 125 | 10 | Central |
WSTII250/10-6×5 | 250 | 10 | Central |
WSTII125/35-4×3 | 125 | 35 | Central |
WSTII250/35-4×3 | 250 | 35 | Central |
WSTII125/35-6×5 | 125 | 35 | Central |
WSTII250/35-6×5 | 250 | 35 | Central |
