Product Details
| Condition | New | Brand Name | Zhengzhou Shuliy Machinery Co.,ltd | |
| Model Number | CE-140 CE-180 CE-300 | Voltage | 220v,240v,380v,400v,415v | |
| Power(W) | 11kw,18.5kw,45kw | Weight | 1100kg | |
| Dimension(L*W*H) | According to different type | Certification | ISO/CE | |
| Warranty | 12months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Charcoal extruder
Charcoal extruding is a kind of machine which can make coal powder,charcoal powder into a certain shape. The shapes of final products are various, they can be finger shape,bar shape, cubic, hexagon,etc.After the coal powder poured into machine chamber, it bears tremendous pressure. With thehelp of all kinds of shaped molds,it will be shaped into certain shapes.
MAIN PARAMETERS
Model | CE-140 model | CE-180 model | CE-300 model |
Capacity ---Charcoal | 400-600kg/h | 600-800kg/h | 2000-3500kg/h |
Capacity ---Coal | 1-2T/h | 2-3t/h | 4-6t/h |
Diameter (mm) | 20-40 | 20-60 | 20-80 |
Motor power | 11 KW | 18.5KW | 45kw |
Weight | 1.2T | 2.5T | 8T |
Dimension | 1700*1200*600mm | 2000*1400*700mm | 2200*1450*800mm |
Working principle
The working principle of the extruder machine: the motor transmits power to transmission through the V- belt. At the same time, the transmission output shaft transmits power to propeller through the floating coupling, and the thruster of propeller push forward coal or charcoal through forming die to produce the ideal high-pressure coal-stick or charcoal stick.
Final productions' features:
1) long burning time.
2) high density and high hardness.
3) stable shape
