TN-ORIENT Sawdust Pellet Press (CE; 4 Patents; 20 Hrs Continuous Running)

Specifications

TN-ORIENT  Sawdust Pellet Press (CE; 4 Patents; 20 hrs Continuous Running) is designed for the industrial production which includes MZLH-420 with output 800-1000kg/1hour; MZLH-600 with output 1500-2500kg/1hour; and MZLH-800 with output 3500-4500kg/1hour.

Pelletizing is the process of making waste materials into solid fuel. The objects are used for burning purposes. Wood pellet can be made from any type of agro-forestry waste: groundnut shell, sugarcane bio-gases, caster shells/stalk, saw dust, coffee husk, paddy straw, sunflower stalk, cotton stalks, tobacco waste mustard stalk, jute waste, bamboo dust, tea waste, wheat straw, palm husk, soybeans husk, coir pitch barks/straws, rice husks, forestry wastes, wood chips and many other agro wastes.

TN-ORIENT   Sawdust Pellet Press (CE; 4 Patents; 20 hrs Continuous Running) is the most important equipment, which has the following features:

The lubrication system for   Sawdust Pellet Press  adopts the tracing and inspecting system controlled by the microcomputer. When the temperature of the bearing is over the normal temperature, the microcomputer will start the round closed Auto-Lubrication System to lubricate the bearings, which complete solved the trouble of lubricating roller depending on the operation experience. The Lubrication System is made up of the tracing and inspecting system controlled by the microcomputer, auto-lubricating system on time and compelled lubricating system by hand.

Driving Gear adopts the high precision gear transmission structure. The wear bearing is made from China Biggest Bearing Manufacturer according to our special requests. The ring die adopts the hoop fastening method, which is increasing the speed of discharge comparing with the past bolt fastening method. As a result, the capacity is 10-15% higher than the belt transmission structure.

As per the ring die and roller of the   Sawdust Pellet Press, we have the fine machining with the alloyed steel, such as 20 CrMnTi and 40Cr; and stainless steel, such as 4 Cr13 and 3 Cr13. And our heating treatment is also different from the other domestic manufacturer, our carburizing treatment make the depth of hard facing to 2mm, which improve the anti-abrasion of the ring die and roller more than 10 times, it can save the production cost heavily.

Model: MZLH420    Sawdust Pellet Press
Capacity: 800-1,000t/h
Power: 90 + 0 x 2 + 2.2kW
Roller and ring die’s life: 800-1,000MT
Consumption of electricity: 70kWh
Materials of dies and rollers: 40Cr steel and carburizing processing With 0.5-1mm thickness

Model: MZLH600   Sawdust Pellet Press
Capacity: 1,800-2,200t/h
Power: 160 +1 x 2+3kW
Roller and ring die’s life: 1,800-2,000MT
Consumption of electricity: 150kWh
Materials of dies and rollers: 40Cr steel and carburizing processing With 0.5-1mm thickness

Model: MZLH800   Sawdust Pellet Press
Capacity: 4,000-5,000t/h
Power: 320+3 x 2+5kW
Roller and ring die’s life: 3,600-4,000MT
Consumption of electricity: 260kWh
Materials of dies and rollers: 40Cr steel and carburizing processing With 0.5-1mm thickness

 Inside Structure of MZLH-Series   Sawdust Pellet Press Plenty of Storage of    Sawdust Pellet Press

                                              1ton/1hour wood pellet production line (  Sawdust Pellet Press )

                                              2ton/1hour wood pellet production line ( Sawdust Pellet Press  )
