WANDA Hot Seller Prickly Pear Oil Press
- Shanghai/Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Usage | Other, prickly pear oil | |
| Type | Other, Cold & Hot Pressing Machine | Automatic Grade | Semi-Automatic | |
| Production Capacity | 900kg/h | Place of Origin | Henan, China | |
| Brand Name | WANDA | Model Number | 6yy | |
| Voltage | 220v | Power(W) | 4kw | |
| Dimension(L*W*H) | 1.5*1.2*2.6M | Weight | 2400kg | |
| Certification | ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1low consumption2 high efficiency
3 less occupied area
4 high oil output
prickly pear oil press
Specifications
automatic hydraulic oil press
1.fully automatic
2.hydraulic
3.more saves time and effort
specifications:
| No. | Item | Unit | Parameter | |
| 1 | Overall Dimension(L× W ×H) | mm | 1450×1200×2200 | |
| 2 | Structure Weight | kg | 2440 | |
| 3 | Productivity | T/24h | 3.5 (Peanut) | |
| 4 | Nominal Capacity per Barrel | L | 150 | |
| 5 | Total Pressure | MN | 308 | |
| 6 | Working Pressure | High Pressure | Mpa | 50 |
| Low Pressure | Mpa | 8 | ||
| 7 | Cylinder Piston Diameter | mm | 280 | |
| 8 | Cylinder Piston Maximum Stroke | mm | 560 | |
| 9 | Barrel (Length × Inner Diameter) | mm | 670x560 | |
| 10 | High Pressure Pump Piston Diameter | mm | 6.5 | |
| 11 | Pump Piston Stroke | mm | 7.6 | |
| 12 | Pump Type | / | High Pressure Pump:R5×6.5 Plunger Pump | |
| Low Pressure Pump: 310 Gear Pump | ||||
| 13 | Power | kw | 2.2 | |
National High and New Technology Enterprise. Among the 15 patent application, 12 patent authorization have been obtained. The self-developed 6YY Series of Ultrahigh Pressure Automatic Hydraulic Oil Press, has won the Provincial Agricultural Machinery Appraisal and Promotion Certificate, has passed the identification of Shandong Province New Product Identification and Inspection Committee, and passed the identification of Linyi Municipal Scientific and Technological Achievements Identification and Inspection Committee.
Besides introducing deep hole boring machine of high-end properties and CNC machining center, it learns advanced processing experience home and abroad, and boldly practices new materials and new technology, which makes the company be the leading one, and, as always,walk in the forefront of the industry manufacturing technology.
It adopts excellent and prudent management concept, and owns strong technical design capability.With the help of advanced computer aided design system and the absorption of the essence of the frontier technologies, our advanced design is in accordance with users’ idea, which makes our products more perfect. Our sophisticated processing equipments, together with meticulous control program, rigorous and accurate detection means, guarantee our products being more outstanding and let the users be more rest assured.
Our unremitting pursuit is to provide customers with satisfactory products.Our products are sold throughout the whole country, and win widespreadpraise and heartfelt trustfrom customers.We promise to provide products with the most reliable quality and to offer the most efficient service.
Chrome Plating Manufacture Line
It uses the world- class advanced hydraulic system, and the power source is ultrahigh pressure combined hydraulic pump station.The most high working pressure can reach 63Mpa. The cake surface unit pressure can be up to 13-30 Mpa, which doubles the pressure of the national standard.Our oil press has the advantages of high pressure, high oil yield, compact structure and controlled heating.Besides that, it is not only highly efficient and energy saving, but also environmental friendly and clean. It is easy and safe to operate the oil press, which dramatically reduces labor intensity. It can be widely used in the pressing of oil plants .it is specail for cold oil press and hard seeds.
| Model No. | pressure(t) | Working pressure(Mpa) | Barrel ID(mm) | Barrel capacity(Kg) | Piston stroke(mm) | Average | Main engine Power(KW) | Ribbon heater power(KW) |
| efficiency(Kg/8h) | ||||||||
| 6YY-160-230 | 50 | 25 | 230 | 25 | 500 | 200 | 1.5 | 4 |
| 6YY-260-410 | 165 | 31.5 | 410 | 80 | 500 | 700 | 1.5 | 4 |
| 6YY-260-460 | 210 | 40 | 460 | 110 | 500 | 900 | 1.5 | 4 |
| 6YY-260-460A | 240 | 45 | 460 | 150 | 700 | 1200 | 1.5 | 4 |
| 6YY-260-460B | 210 | 40 | 460 | 150 | 700 | 1200 | 1.5 | 4 |
| 6YY-280-560X | 340 | 55 | 560 | 200 | 670 | 1800 | 2.2 | 4 |
| 6YY-280-500X | 248 | 40 | 500 | 200 | 700 | 1500 | 2.2 | 4 |
| 6YY-260-460X | 210 | 40 | 460 | 150 | 700 | 1200 | 2.2 | 4 |

mpany services: We will projects and technical parameters according to the users' requirements.
Medium-sales services: we guarantee to choose raw materials in the process of production strictly according to contract requirement. Free-on-the- spot guidance, installation as well as customer training about equipment maintenance and correct application methods are available.
After-sales service: We will establish a complete user files to achieve one file for each customer. We can provide accurante and fast service for customers
