Glass magnesium board production manufacturer
- 11 Set / Sets per Month
- Tianjin
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | FC | |
| Model Number | FC-A021 |
Product Description
Specifications
full or semi-automaticlower labors and power cost
high output and multifunction
quality guarantee
installation directions
This production can make all kinds of board with many functions, such as: double face non-woven fabric, single face non-woven fabric, sanding board, multilayer fiber-glass fabric etc.
The parameter of annual production 1.35 million sq.m automatic magnesium board production line.
1 Production plan and major technology
1) production plan
Magnesium fireproofing board comply with national standard FM-BJC688
Specification:
Thickness: 2-24mm
Width:1200mm-1220mm
Length:2400mm-3000mm
Type: currently magnesium fireproofing board, sanding and refining fireproofing board
2) Major technology
Material: decided according to the situation of buyer
Manufacturing course: (1 ) complete automatic type
( 2 ) semi-automatic type
2 Main equipment list
Item | Equipment name |
Dosage control system | Automatic batch turning system Microcomputer control system Dust collection system Elevating conveying system Automatic measure system Shell fabric mixing system Middle material mixing system Pulp stock mixing system Accessories dressing by screen system Blending agent dessolving system Blending agen dessolving and automatic measurement system |
Forming system | Vaccum compressed air control system Automatic mould system Forming conveying system Rolling forming system Automatic cutting board system Automatic collecting board twinlift system Computer touching control system Speedup rod road Loading vehicle changing tracksystem |
Curing system | Constant temperature system in curing room Curing room automatic humidity controlled system Automatic stripping system Automatic stacking board system Forklift |
Arranging board system | Rod road conveying system Horizontal and perpendcular high speed cutting machine Landscape orientation conveyor Sanding machine Dust colletion system Microcomputer self-control system Power distributing system |
3 Major indicate
A: Annual production capacity 1.35 million square meters
B: raw material:
Magnesium chloride 563 ton / year
Magnesium oxide 3375 ton / year
Fiberglass fabric 900000 meters / year
Plant fiber 506-843 ton / year
Perlite 330 ton-506 ton
Modifier 101 ton / year
Water 5000 ton / year
Installed power 300 KW
