Glass Magnesium Board Production Line

Specifications

 glass magnesium board machinery

Detail information:

1. The production line of per shift (according to 8 hours) production capacity

is up to 1500 pieces, size is 1200 * 2400 * 8mm.

2. Boards thickness range: thickness is from 3mm to 24mm, length is from

2400 to 3000mm. Width is from 1200 to 1220mm.

3. The production line can produce a variety of performance sheet: for example,

double-sided non-woven sheet, single-sided non-woven sheet, sanding board

(two sides), multi-layer glass fiber cloth boards (1-2 middle layer of glass fiber cloth)

and other boards.

The high degree of automation production line, which is equipped with:

a). Automatical metering- feeding system

b). Mixing system

c). Automatic mould supplying

d). Auto- demoulding agent system

e). Automatic spread slurry, auto spread non-woven and glass fiber systems

f). Auto- roll molding system

g). Automatic cutting tape, cutting system

h). Automatically into the conservation frame, convey into the maintenance room system

i). Automatic demoulding System

j). The production line is equipped with automatically controlled temperature

conservation rooms, ensure that plate in the hydration reaction in the conditions

require, so that the production of the plate with more quality assurance

The finished glass magnesium oxide boards:
