Hot Selling 500kg/h Wood Pellet Production Line

Specifications

hot selling 500kg/h wood pellet production line

Machine introduction

Small wood pellet production line mainly focus on small capacity like 200-300kg/h, 300-400kg/h, 400-500kg/h, 500 to 600kg/h. The best material dimension for producing pellets is 1 to 5mm, the best material moisture content for producing pellet is roughly 8 to 15%. Then, if your material has big difference with the above, don’t worry, this pellet production line can help you to make it perfect.

There are the crushing process, conveying process, drying process, conveying, pelletizing process and cooling process included in the line.

Crushing process

There are two types crusing machine. One is Crusher, the other is Hammer Mill. These two types machine is divided according to material dimension. If your machine diameter within 5 to 50mm, then we recommend Hamme Mill for your using. If your material diameter within 50-250mm, then we recommend Crusher for your using.

Drying process

There are two kinds drying machine. One kind Dryer with one stove, the other kind Dryer with two stoves. These two types machine is divided according to material moisture and customer request for the capacity.

Pelletizing process

HSKLN series flat die pellet machine is special design for producing wood pellets. Adavantage of machine as following, please check:
1,Gearbox.There is the gearbox connect with machine. Thus rotating speed of main shaft is reduced. With the speed reducing, roller will have higher pressure for the die. It can help to increase pellets density.
2,Oil circulating system. There is the oil pump connect with machine. It will circulate oil between gearbox and machine shaft. Thus, it has the function of cooling shaft temperature, and to lubricate machine.
3,Rotating roller and stationary die. As we know, roller is work vertical on die. With the shaft speed reducing, it will increase machine pressure. Meanwhile, it will increase the density of fuel pellets.

Cooling process

It is one set Cooler for the cooling process. After pellets going through this part, you will get pellets with ready moisture, ready remperature and pure pellets.

My friends, if you are looking for the wood pellet production line with small capacity. Please try to contact us. We will provide our experience for this field, detailed machine specification and powerful technical supporting. Meanwhile, welcome you to come to visit our factory.

Any questions, please don’t hesitate to contact Linda. You can add my online chatting tool Skype ID: ephammermill  I am still online for technical supporting.

Hot selling 500kg/h wood pellet production line purchased by Russian customer

Hot selling 500kg/h wood pellet production line purchased by Spain customer
