Home > Products > Stone Polishing Machine > RPM STONE POLISHER---SHANDONG CHINA
RPM STONE POLISHER---SHANDONG CHINA
- Qingdao
- T/T Money Gram Credit Card
You May Like
Product Details
| Condition | New | Type | Stone Cutting Machine | |
| Use | Granite | Place of Origin | Shandong, China | |
| Brand Name | Huaxing | Model Number | RPM09/9A | |
| Voltage | 380V 50HZ | Power(W) | 71.6kw | |
| Dimension(L*W*H) | 5500*2200*2200mm | Weight | 7000kgs | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
RPM SERIES RESIN ABRAISIVE POLISHING MACHINE
Model
RPM09/9A RPM09/12N RPM12/9 RPM12/12N
polishing width: 300~950mm 300~950mm 300~1250mm 300~1250mm
polishing thickness: 15~30mm 15~30mm 15~30mm 15~30mm
No. of the polishing heads: 9 12 9 12
Total capacity: 71.6 kw 97.5 kw 71.6 kw 97.5kw
polishing head motor: 7.5kw*9 7.5kw*12 7.5kw*9 12*7.5kw
belt drive motor 1.1 kw 1.5 kw 1.1 kw 1.5kw
crossbeam swinging motor: 3 kw 3 kw*2 3 kw 2* 3kw
air pressure of compressor: 0.60~0.8Mpa 0.60~0.8Mpa 0.60~0.8Mpa 0.60~0.8Mpa
air displacemet of the compressor 500L/min 500L/min 500L/min 500L/min
pressure of the cooling water: 0.15~0.3Mpa 0.15~0.3MPa 0.15~0.3Mpa 0.15~0.3Mpa
water consumption of each head: 25L/min 25L/min 25L/min 25L/min
overall dimension: 5500*2200*2200mm 7200*2300*2400mm 5850*2650*2350mm 7200*2650*2400mm
diameter of polishing disk: 200mm 200mm 200mm 200mm
the effective stroke of crossbeam swinging 800mm 800mm 1100mm 1100mm
effective up-down stroke of polishing head 90mm 90mm 90mm 90mm
total weight 7000kg 10000KG 8700kg 10500 kg
