TAIYU Chicken Water Feeding System
- XINGANG
- Credit Card
You May Like
Product Details
| Use | Chicken | Type | 120 birds per set | |
| Material | Q195 steel wire, Q235 | Place of Origin | Hebei, China | |
| Brand Name | TAIYU | Model Number | A type |
Product Description
Specifications
Chicken water feeding systemA type chicken cage
Hot and cold galvanized cage
could be used 5-year to 30-year
Chicken Water Feeding System
My details including:
NO.1: Chicken Water Feeding System's Introduction
NO.2: Chicken Water Feeding System's Customers details from Different Countries
NO.3: Chicken Water Feeding System's Cage suggestion due to different countries
NO.4: Chicken Water Feeding System's Necessary accessories of cage
NO.5: Chicken Water Feeding System's Farm Projects
NO.6: My connection
NO.1: Chicken Water Feeding System's Introduction
| Material | 1. Common light galvanized mesh cage | Lifespan: 5-year to 8-year |
| 2. Full deep galvanized mesh cage | Lifespan: 20-year to 30-year | |
| 3. PVC coated mesh cage | Lifespan: 10-year to 20-year | |
| Feature | High stocking density, up to 6 tiers possible Anti-corrosive, Durable and easy to install No more manure marks&hair cracks on eggs Excellent dehydration of manure | |
| Production Capacity | 50 units per day, in 20 days per 2*40 feet, in 30 days per 5*40 feet | |
| Application | Egg laying chicken, breeding chicken, broilers | |
| After service | Freely change the new fittings in 3-year to 5-year at local agents' shops as different quality ordered | |
NO.2: Chicken Water Feeding System's Customers details from Different Countries
We have worked in this line for a long time, there are many customers bought our cages. our quality and design have been approved by the farmers and market. please check the details.
| KENYA | REUBEN##### | 00254#####5 |
| NIGERIA | MUHAMMAD##### | 00234#####4 |
| TANZANIA | GEORGE##### | 00255#####8 |
| ZAMBIA | PAUL##### | 00260#####8 |
| UGANDA | NILUS##### | 00256#####4 |
| ZIMBABWE | CHRIS##### | 00263#####0 |
| MALAWI | STEVE##### | 00265#####1 |
NO.3: Chicken Water Feeding System's Cage suggestion due to different countries
Different countries have different climates, and different clients have build different house.
First one, it is popular in Kenya, Zimbabwe, Malawi, Zambia
| Type-L2 | A type, 3 tiers, battery cage, two sides |
| Size per unit | 2m by 1.8m by 1.62m (Length, width, height) |
| Set Capacity | 120 birds per set |
| Cell Capacity | 4 birds per cell, 30 cells per cage |
| Galvanzation | Cold galvanization |
| Lifespan | could be used 5-15 years as different quality |
| Raise period | 16 weeks to 72 weeks |
| Cage advice | 5000 layers need 42 sets |
| Farm design | put into 2 rows, 46m by 7m by 3.5m |
| Fittings | cage, cage frame, water pipe, drinkers, feeders, other necessary fittings Drinking system is automatic, will load some for free |
Second one, it is popular in Nigeria, Uganda, Tanzania
| Type-L4 | A type, 3 tiers, battery cage, two sides |
| Size per unit | 2.2m by 2.4m by 1.65m (Length, width, height) |
| Set Capacity | 120 birds per set |
| Cell Capacity | 4 birds per cell, 30 cells per cage |
| Galvanzation | Hot dipped galvanization |
| Lifespan | could be used 20-30 years as different quality |
| Raise period | 16 weeks to 72 weeks |
| Cage advice | 5000 layers need 42 sets |
| Farm design | put into 2 rows, 50m by 8m by 3.5m |
| Fittings | cage, cage frame, water pipe, drinkers, feeders, other necessary fittings Drinking system is automatic, will load some for free |
NO.4:Chicken Water Feeding System's Necessary accessories of cage
| Cage Mesh | wire diameter from 2.0mm to 4.0mm cold galvanized or hot deep galvanized |
| Cage Frame | Angle bar frame and U-type steel frame |
| Feeding Trough | 1) 80*90*110mm 2)70*80*120mm 3)70*80*90mm The loading capacity of each layer of one group:60KG/PC Above size is as to different usage, different quality |
| Water Pressure/water tank | Supply cleaning and average fresh water for each chicken |
| Drinkers | Stainless steel nipple drinkers Warranty of best quality is 15 years water-tight, external uses the recycled plastic, prolong the lifespan |
| Water Pipe | Could be used for a long time under high and low temperature, not crack easily |
NO.5: Chicken Water Feeding System's Farm Projects
There are many farms using our cages, such as Nigeria, Kenya, Tanzania, Uganda, Zimbabwe, Zambia, Malawi and so on, our quality and design have been approved by the farmers and market.
NO.6: My connection
