TAIYU Kenya Poultry Farm Automatic Chicken Lay

Item

Broiler Cage

Egg Laying Chicken Cage

3-tier /2-door

3-tier /5-door

Set capacity

120 birds

120 birds

Cell capacity

10 birds

4 birds

Cage size

  5.25 by 6.89 by 5.4 feet

7.2 by 7.9 by 5.0 feet

Cell size

31.5 by 13.8 by 16.54 inch

16.9 by 16.6 by 16.5inch

Fittings

Cages, cage frame, water pipe, drinkers, feeders, other necessary fittings. Drinking system is automatic, after installation then put birds and food.

Materials

Q195  steel  wire , Q235  steel  wire

Recommended  Sets/Row

Lifespan

5 years to 30 years as different countries' climate and poultry house design

Item

Specification

Source Type

AC, 3-Phase

Rated Power

0.75KW - 0.11KW

Rated Voltage

220V/380V

Outline Size

L by W by H = (2.3-2.7) by (1.2-1.5) by (2.0-2.25)m

Hopper Size

L by W by H = 0.66m by 0.256m by 0.5m

Working Average Rate of  the Hopper

Around 15 g/m

Feed Capacity of each Hopper

35KGS - 100 KGS/piece

Working Speed

10 - 15 Meters/Min

Structure Weight

550KG

Supporting Orbits

Thickness = 3.0mm

Diam = 50mm

Orbits Material

Hot deep galvanized Pipe

Transverse Auger Conveying Feeding Equipment

Diameter = 75mm to 150mm

Connected with the Silo

5,000KGS to 15,000KGS

Items

Specifications

Size(L×W×H)

(2.2~2.8) M × (1.0~1.5) M × (2.0~2.6) M

Source Type

AC,3-Phase Source

Rated Voltage

380V

Rated Power

0.75~3.0KW

Egg collection ability

>3000 PIECES/HOUR

Egg Broken Rate

≤1%

Belt Working Speed

1~3 M/MIN

Working Type

4 tiers working together

Paint Thickness

≥0.05MM

Machine Weight

700KGS

Egg collecting belt

Common one and Best quality imported from Italy

Egg collecting belt width

100MM

2.easy installation , maintenance and operation

3. save electricity, one day open one time

Country

Customer name

Address

Telephone No.

 KENYA

  XXX PAUL

  P.O BOX XXX,XXX PLAZA NAIROBI

00254XXXXXXXX5

 TANZANIA

  XXX ALI KHAMIS

  TIP NO. 1XXXXXXX2

00255XXXXXXX2

0255XXXXXXX6

 UGANDA

  BENJAMIN XXX

 XXX TOWN COUNCIL WAKISO DISTRICT

00256XXXXXXXX6

 NIGERIA

  BOLAJI XXX

  XXX, LAGOS-BADAGRY EXPRESS WAY

0023470XXXXXXX9

Welcome joining,visit customers every year.

Welcome to visit agent's office or farms to check the quality and get more details.

The above information is just some agents for refference, please call or email us to get the full information.
