Ceramic Cross-Partition Ring
- 5000 Cubic Meter / Cubic Meters per Month
- SHENZHEN SHANGHAI
- T/T
You May Like
Product Details
| Place of Origin | Jiangxi, China | Type | Ceramic Rings | |
| Application | Industrial Ceramic | Material | Alumina Ceramic | |
| Model Number | Ceramic Cross-Partition Ring | Brand Name | KANGYU |
Product Description
Specifications
Cross-Partition RingSize:50mm 50mm 100mm 120mm 150mm
Cross-Partition Ring
Introduction
Ceramic Cross Partition Ring is a kind of random packing further improved on the basis of Raschig Ring, adding the cross clapboard inside the ring. It increases the ring’s surface area, improving significantly the mass transfer efficiency of vapor and liquid.
Application
Ceramic Cross Partition Ring can be widely used for drying tower,absorption tower,cooling tower and regeration tower of chemical, metallurgy,gas, oxygen and other industries.
Technical Data
Spec. | D*H*T(mm) | Surface area (m²/m³) | Free volume (%) | Number per m³ | Bulk density (Kg/m³) | Dry Packing Factor (m-1) |
Ø 50 | 50*40*50*5 | 145 | 50 | 6400 | 600 | 565 |
Ø 80 | 80*64*80*8 | 120 | 56 | 1950 | 820 | 356 |
Ø100 | 100*80*100*10 | 110 | 53 | 1000 | 850 | 252 |
Ø120 | 120*96*120*12 | 75 | 55 | 370 | 860 | 146 |
Ø150 | 150*120*150*15 | 60 | 58 | 295 | 980 | 101 |
