BXMQ2016 Super Heavy Planer Milling Machines

FOB Price

Negotiable / Unit

1 Unit(Min. Order)

Port Shanghai Port or Qingdao Port

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Liaoning, China
Brand Name	Acecare Tech	Model Number	BXMQ20 Series
Type	Other, Gantry	CNC or Not	Normal
Power(W)	22-45kw	Weight	6000-18000kg

Product Description

BXMQ20 Series Super Heavy Planer Milling Machines

Main transmission adopts SRD or servo system,wide range of stepless speed change of table's movement satisfies the requirements of planing/milling/grinding at different speed, independent spindle feeding box enables more balanced feeding to process plane/inclined plane/T slot/combined guideway/rack,etc.

1.To drag high-precision rack with multi-head worm to realize more stable table movement.

2.To get enough lubrication of table at any speed with independent lubrication system.

3.The adoption of heat-treatment techniques like drawing the temper off/quiver-ageing/hyperacoustic quenching on key parts as the machine body/column enables more stable accuracy and longer working life.

4.Machine body/column/beam/table are designed according to the parameters of heavy-duty machines, and the material is cast iron (≥HT250),so the machine is with better stability & accuracy retentivity.

Specifications					BXM20 series Super Heavy Planer Milling Machines
					BXM 2016A	BXM 2016B	BXM 2016C		BXM 2016D			BXM 220A	BXM 220B	BXM 220C	BXM 220D	BXM 220E
Max. workpiece dimensions		Length mm			3000	4000	6000		8000			4000	6000	8000	10000	12000
		Width mm			1600	1600	1600		1600			2000	2000	2000	2000	2000
		Height mm			1200	1200	1500		1500			1500	1500	1500	1500	1500
Max. workpiece weight kg					6000	8000	10000		12000			10000	12000	14000	16000	18000
Table motor power kw					22	22	30		37			30	30	37	37	45
Table	Length mm				3000	4000	6000		8000			4000	6000	8000	10000	12000
	Width mm				1200	1200	1200		1200			1600	1600	1600	1600	1600
	Max. pull of rack				88000 (N)
	Feeding speed m/min				0.08-30(Stepless)
Distance between columns mm					1620	1620	1620		1620			2020	2020	2020	2020	2020
Feeding rate of vertical tool rest				Horizontal mm	0.2-20(Stepless)
				Vertical mm	0.2-20(Stepless)
Feeding rate of side tool rest mm					0.2-6(Stepless)
Beam up/down speed mm/min					360
Max.sectional area of planing arbor mm					40 x 40					60 x 60
External dimensions			Length mm		6700	8700	12700	16700			8700		12700	16700	20700	24700
			Width mm		3900	3900	3900	3900			4300		4300	4300	4300	4300
			Height mm		3200	3200	3500	3500			3500		3500	3500	3500	3500
