X6325 Milling Machine, Universal Radial Miller
- Qingdao Port or Shanghai Port
You May Like
-
X6323A Universal Milling Machine,radial Milling Machine
-
X6323A Universal Radial Milling Machine,radial Milling Machine
-
Cylindrical Grinding Machine M13 Series,grinding Machine, Cylindrical Grinding Machine
-
CK6130 CNC Lathe Machine, CNC Lathe Machine, Lathe
-
Z3040*13 RADIAL DRILLING MACHINE,drilling Machine,radial Drilling Machine
-
M618A Surface Grinding Machine,sureface Grinding Machine, Grinding Machine
Product Details
| Condition | New | Place of Origin | Liaoning, China | |
| Brand Name | Acecare Tech | Model Number | X6325B | |
| Type | Universal | CNC or Not | Normal | |
| Power(W) | 2.25kw | Dimension(L*W*H) | 1516*1550*2080mm | |
| Weight | About 1420KG |
Product Description
X6325B Universal Radial Milling Machine
1.Table Size 254*1270mm
2.Ram Travel 470mm
Milling Machine MODEL
| X6325B | |
Table size | 254×1270(10"×50") | |
254×1370(10"×54") | ||
Long travel(mm) | 850/950 | |
Cross travel(mm) | 400 | |
Vertical travel(mm) | 420 | |
T-slot No. and size(mm) | 3x16 | |
Ram travel(mm) | 470 | |
Distance from spindle nose to table surface(mm) | 0-405 | |
Spindle hole taper | (standard): R8 (optional): ISO30/ISO40 | |
Spindle travel | 127mm | |
Spindle speed | (standard):16 shift grade 50HZ65-4500 60HZ:80-5440 | |
(optional): variable65-4500 | ||
Auto. quill feed | (three steps): 0.04(0.0015")/0.08(0.003")/0.15(0.006")mm/revolution | |
Spindle motor | 2.25Kw/3HP | |
Head swivel | 90° | |
Head tilting | 45° | |
PACKING SIZE | One miller per case | 1516×1550×2080 |
Two miller per case | 1650×1790×2170 | |
Three miller per case | 1650×2285×2235 | |
Gross Weight(Kg) | 1420 | |
