Intermittent ball mill
- 10000 Piece / Pieces per Month
- FOB Tianjin/Shanghai
You May Like
Product Details
| Condition | New | Type | Ball Mill | |
| Capacity(t/h) | 0.2-10 | Place of Origin | Henan, China | |
| Brand Name | HT | Model Number | TCQ |
Product Description
Intermittent ball mill
Model | Capacity (t/time) | Rotary speed (r/min) | Power(kw) | Weight (t) |
TCQ910×1120 | 0.2 | 36 | 5.5-11 | 2.6 |
TCQ1200×1400 | 0.5 | 32 | 11-18.5 | 4.3 |
TCQ1500×1800 | 1 | 28 | 15-22 | 6.5 |
TCQ1800×2100 | 1.5 | 26 | 18.5-30 | 8.8 |
TCQ2100×2100 | 2.5 | 22 | 22-37 | 13 |
TCQ2200×2400 | 3 | 20 | 28-45 | 15 |
TCQ2500×2900 | 5 | 16 | 37-55 | 19 |
TCQ2800×3700 | 8 | 14.5 | 55-75 | 26 |
TCQ3000×3700 | 10 | 14 | 75-90 | 32 |
Intermittent ball mill also called ceramic ball mill, adopting dry and wet method intermittent homework, it is used for fine grinding the raw material such as feldspar, quartz, clay, ore . It is grinded according to the times. Intermittent ball mill (ceramic ball mill) is mainly used to mix the raw materials, grinding, the product the fine degree of uniformity, save power. Not only can dry grinding, can also be wet grind.
Main Usage:
Intermittent ball mill is the key equipment for the material after being broken, and then to smash. It is widely used in cement products, new building materials, refractory material, chemical fertilizer, black and non-ferrous metal ore dressing with glass ceramics production industry, it will dry or wet grind for all kinds of ores and other materials.
Working principle
Intermittent ball mill consist of feed , discharge, transmission (reducer, small transmission gears, motor, electric control) and other major parts. Hollow shaft with steel castings, lining systems can be replaced, return big gear is processed with cast hobbing, the cylinder body set have wear-resisting lining board, having good abrasion resistance. This machine is smooth operation, reliable.
Characteristic:
Energy saving electricity, novel structure, convenient operation, use safety, performance reliable. It is suitable to common diaphragm special materials mixed and grinding operation.
