drum drying machine

FOB Price

USD $20,000 - $200,000 / Set

1 Set(Min.Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Drum Drying Equipment	Place of Origin	China
Brand Name	changgan	Model Number	HZG
Certification	CE	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

HZG rotray drum dryer

wood chip dryer Description
After the damp raw material is put into the drier from on end, it is turned over through strring-up rake inside the cylinder and distributed uniform in the drier and contacted with countercurrent hot air fully. It speeds up heat and mass conducting of dry. During the oeriod of dry, raw material is effcted by stirring-up rake with gradient and hot air, it can be moved and passed through the dry region and to star valve and then discharge the finished product.

rotary drier Technical parameters

item(m)	priductive capacity(t/h)	revolution(r/min)	motor power(Kw)	install angle(^.)	Temp.of final
Φ1.0×5.0	0.5-1.2	0.6-6	4	3-5	≤1.5%
Φ1.2×6-10	1.5-3	0.6-6	5.5	3-5	≤1.5%
Φ1.5×12-18	3-5.5	0.6-6	15	3-5	≤1.5%
Φ1.8×12-18	5-6.5	0.6-6	18.5	3-5	≤1.5%
Φ2.2×12-22	7-12	0.6-6	22	3-5	≤1.5%
Φ2.4×15-20	9-15	0.6-6	30	3-5	≤1.5%
Φ3.0×25	16	0.6-6	55	3-5	≤1.5%

model	heat direct and sequence		heat direct and retrograde		compound heating
type of material	mineral	HP		ammonium sulphate	phosphorus fertilizer	coal
capacity kg/h	1000	-66	15000	20000	12000	5000
primary moisture %	30	13	6	1.5	5	6.5
final moisture %	15	0.3	1	0.1	0.1	0.1
average dim. mm	6.5	0.05	4.7	0.5-0.7	0.5	5
thickness of material mm	770	800	1890	1100	1500	750
capacity of hot air kg/h	39000	5400	10750	9800	6500	16000
temp. of air in	600	165	500	180	650	570
temp. of material out		42	100	70	80	75
heating style	gas	steam electric+heating	heavy oil	coal fuel furnace	heavy oil	heavy oil
ratio of feed		6.3	7	7.5	7.8	18
rotation speed rpm	4	4	3.5	3	4	2
angel ^.	0.04	0.005	0.03	0.05	0.05	0.043
quatity of oar	12	24	12	22	8 16	6 12
dim. of drier m	2.0	1.5	2	2.3	2 0.84	24 0.95
length of drier m	20	12	17	15	10	16
driving power kw	22	7.5	15	11	11	15
