Chilwee Lithium Ion BN7220 LE for Small UPS Applications

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Accessories

Certifications

FEATURES

• 'Silver Fish' design, elegance and portable
• 'Green" and environment-friendly, no pollution to the environment during production and normal usage
• Stable structure and simplified production process enables mass production and easy maintenance
• Completely new protection design of water-proof, fire-proof, shock-resistance enable high safety
• Professional protection module and BMS ensures the battery pack to be protected perfectly
• High weight and measurement specific energy ensures the battery pack extremely long-voyage ability
• Super long life supported by innovative technologies, high quality material and strict manufacturing control

Battery parameters

Battery Model No.		BN7220LE
Material		MnNiCo Ternary Material + LiMn2O4
Nominal Voltage (V)		72V
Nominal Capacity (C2, 25℃ )		20Ah
Battery Pack Dimension (mm)		300mm X 181mm X 150mm (L X W X H)
Nominal Weight (Kg)		11Kgs ± 0.1
Continuous Charge Current (A)		4A
Charge Time (hr)		4h - 6h
Discharge Cut-off Voltage (V)		≥ 59V
Continuous Discharge Current (A)		≤ 15A
Pulse Discharge Current (A)		≤ 25A
Cycle Life at 100% D.O.D.		≥ 700 Cycles
Capacity Retention Rate at 0℃		≥ 90%
Self-Discharge Rate (25℃)		≤ 5% per month
Temperature Characteristic	Charging	-20℃ - 40℃
	Discharging	-20℃ - 40℃
	Storage	-20℃ - 40℃
