Fully Automatic Small Tablet Blister Filling and Sealing Machine

FOB Price

US$ 7,500 - 10,500 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Medical
Automatic Grade	Automatic	Driven Type	Other, Peneumatic and Electric
Voltage	220V 50HZ	Power	4KW
Place of Origin	Zhejiang, China	Brand Name	JINDE
Model Number	JDPP-140	Dimension(LWH)	2280 x750 x1650 mm
Weight	700kg	Certification	CE
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

filling and sealing machine
1. CE, GMP
2.SUS304
3.Operate is convent ,save labor, save material
4. Low price

Fully automatic small tablet blister filling and sealing machine

Main characteristics:

1. Cold punching forming moulds makes blister stiff and uniform;

2. Human-computer interface, PLC control, variable frequency stepless speed regu- lating;

3. Professional feeder, adopting feeding method of multi-stage vibration,pipeline baiting,

4. Automatically detect missing tablets (pellets), and automatically reject waste plate;

5. Can be equipped with cursor GC register device;

6. With cylinder heat-sealing, the upper and nether checkers ensure the effect of heat-sealing,

and waster automatically recovering device.

Main Technical Parameter1

Blanking Plate	2-3 plates/ time (according to your product width)
Blanking Frequency	20-40 times/min
Blister size	57x90 mm(standard blister size,your size different and need to arrange it)
PVC size (Max )	0.15 to 0.5) x140 mm
Max forming Area and Depth	140 x100 x18mm
Adjustable Scope of Travel	30-110mm
Pressure air	≥0.15m3/min
Pressure Power	0.6Mpa 220V 50HZ 4KW
Machine Size	2280 x750 x1650 mm
Packaging Size	2400 x870 x1800mm
Machine Weight	700 kg

Some Part of this Machine:

Samples :
