Home > Products > More product > Digital RGB Led Strip 60LED Apa102 5m/roll

Digital RGB Led Strip 60LED Apa102 5m/roll

FOB Price

US$ 9 - 12 / Meter

10 Meters(Min. Order)

Port Shenzhen Yantian
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	epistar smd5050	Type	Flex LED Strips
Input Voltage(V)	5	Lamp Power	14.4
Color Temperature(CCT)	pixel	Working Temperature(℃)	-30, 60
Working Lifetime(Hour)	50000	Lamp Body Material	Copper
Certification	CE	Emitting Color	Changeable
Place of Origin	Guangdong, China	Brand Name	iPixel / SJ
Model Number	SJ-10060-APA102

Product Description

digital RGB led strip 60LED apa102 5m/roll

Description:

Apa102 RGB Flexible Digital LED Strip

These are the Digital strips that can be controlled with computers and other DMX/Digital SD Card Controllers. The advantage of digital strips is that you can control each led by itself so you can make video/chasing effects and other patterns. These color changing LED strips are flexible, bright, and easy to install! They are much brighter and longer-lasting than traditional rope light.

Each roll of flexible LED strip is 16' long (actually 16'-5" or 5 meters with wire on each end). The LED type used are the 5050 type super bright 3 in 1 SMD LEDs. There are 300 per 16' roll. They run on 5V DC. The waterproof rating is IP65/IP67, which means that these flexible LED strips can get wet.

Details These Apa RGB strips can change any color/pattern with the use of a controller or via DMX so you will need a SD Card Controller designed to control the apa102 chip or use standard DMX and a DMX to apa102/104 Converter.

Datasheet

Input voltage	DC5V
Current	2.88A
LED Qty	60pcs SMD 5050 meter
IC Qty	60pcs apa102 IC chips per meter, ic built inside of led
Wave length(NM):	R-650mcd, G-520mcd,B-460mcd
Power(W/M)	14.4W/M
Signal	apa102 chip
View angle	120 degree
Life span	over 50000hrs
Dimension	1000122.2mm
Certification	ce & rohs
WaterProof	IP65 tube, silicon coating
Packaging	5M/reel in antistatic bag

Picture details:

Supply white and black PCB.Non-waterproof and waterproof type both available.

Waterproof type with silicon tube can use outdoor decoration.

4 Pin Male and female Connector, easy for connect.

Controller: DMX controller & decoder & SD controller & arduino controller

Change color individually and addressable full color.

We also supply mini controller and power supply as a kit.

Install: Every 1m with 2 holders and screw to install, and back adhesive on each strips.

Application:

Package: 5m/ rell 50 rell/ carton size: 46*26*46.5cm total weight :100string /carton
