High speed Rotary die head PE film blowing machine
- 25 Set / Sets per Month
- NINGBO/ WENZHOU/SHANGHAI
- T/T Credit Card PayPal
You May Like
-
High Speed PE biodegradable film blowing extrusion machine
-
LDPE,HDPE biodegradable film blowing machine
-
Rotary die head LD/HD PE film blowing machine
-
High Speed LDPE HDPE biodegradable film blowing extrusion machine
-
Rotary die head PE monolayer film blowing machine
-
Full automatic PVC caps bottle cover making machine for water bottle
Product Details
| Condition | New | Application | Film | |
| Plastic Processed | PE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | No | Place of Origin | Zhejiang, China | |
| Brand Name | mingli | Model Number | SJ55 | |
| Voltage | 380 / 220V | Power(W) | 25kw | |
| Dimension(L*W*H) | 2000*1600*3500mm | Weight | 1000kg | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
suitable for LDPE,HDPE,LLDPE
We named RUIAN MINGLI MACHINERY FACTORY before,enlarging the business field by DONGCHENG company.
LDPE HDPE LLDPE film blowing machine for T-shirt bags
Uses:
This unit applies to blowing high-density polyethylene (HDPE), low density polyethylene (LDPE) and linear low density polyethylene (LLDPE) plastic film, widely used in food, clothing, textiles, daily necessities and other civilian goods and industrial packaging. Raw materials through the recipe can produce pearl film and degradation film.
Features:
Screws, barrels 38CRMOALA alloy steel, formed after nitrogen treatment and precision machining, high hardness, corrosion resistance, durable.
Die hard chrome plating, the structure of spiral mandrel type uniform melt extrusion, blown film finish: air-cooled device labyrinth structure with even air output. The traction devices using the lift and down adjustment depending on the process requirements.
3. Coiling unit adopts pressure friction rewinding or center rewinding, driven by torque motor, rewinding and changing easy.
Technical parameters:
| Model | SJ-45 | SJ-50 | SJ-55 |
| screw diameter | ¢ 45mm | ¢ 50mm | ¢ 55mm |
| Screw Ratio | 30:1 (L / D) | 30:1 (L / D) | 30:1 (L / D) |
| screw speed | 10-120 rpm | 10-120 rpm | 10-120 rpm |
| die specifications | 60,80,120 | 60,80,160 | 120,160,200 220 |
| sided product thickness | 0.003-0.12mm | 0.003-0.12mm | 0.003-0.12mm |
| Folding Width | 600mm | 800mm | 1000mm, 1200mm |
| main motor power | 11kw | 13kw | 15kw |
| heating power | 14.3kw | 16kw | 18kw |
| yield | 20-35kg / h | 20-40kg / h | 25-50kg / h |
| Total Power | ≈ 1.8T | ≈ 1.9T | ≈ 2T |
| Dimensions (L x W x H) | 4500×2300×4200mm | 4500×2500×4200mm | 4500×2700×4200mm |
