Product Details

Condition	New	Type	Other, Induction Furnace, induction furnace
Usage	Melting Furnace	Place of Origin	Guangdong, China
Brand Name	Rongdongsheng	Model Number	KGPS--10T

Product Description

Introduction :

Intermediate frequency furnace is a induction heating equipment , Mainly be used in the material of ferrous and non-ferrous metal casting, melting and heating treatment industry , such as iron, steel, brass, cooper ,zinc ,etc. As well as heating treatment prior to forging , sintering and hot rolling in casting and melting industries.

Characteristics :

1.Speedy melting, low production cost , low pollution, conforming to environmental protection requirement

2.Flexibly adjustable power, easy and continuous smooth adjustment, easily controllable temperature, low oxidization loss, uniform metal content

3.Furnace shell with cast aluminum ally or steel shell construction, easy overturn body, available for selection of electric, manual, hydraulic or other overturn mode as needed;

Parameters:


Equipment Type (Furnace capacity)	Power input(Three-phase Four- wire 50/60Hz)			Power Output				Melting Time (Minutes)	Power consumption per ton of material (KW)
Equipment Type (Furnace capacity)	Rating power (KW)	Input Voltage (V)	Input Current (A)	DC Current (A)	DC Voltage (V)	IF Voltage (V)	IF frequency (KHZ)	Melting Time (Minutes)	Steel (KW)	Iron (KW)	Copper (KW)
KGPS--0.05T	50	380	80	100	500	750	1-2.5	20-60	850	800	450
KGPS--0.1T	100	380	160	200	500	750	1-2.5	20-60	800	750	450
KGPS--0.2T	160	380	256	320	500	750	1-2.5	30-70	750	700	440
KGPS--0.25T	160	380	256	320	500	750	1-2.5	30-70	750	700	440
KGPS--0.3T	200	380	320	400	500	750	1-2.5	30-70	700	650	430
KGPS--0.5T	250	380	400	500	500	750	1-2.5	30-70	650	600	430
KGPS--0.75T	400	380	640	800	500	750	1-2.5	40-70	630	580	400
KGPS--1T	600	380	960	1200	500	750	0.7-1	40-70	600	560	390
KGPS--1.5T	1000	380	1600	2000	500	750	0.7-1	50-70	580	530	380
KGPS--1.5T	1000	660	912	1140	880	1300	0.7-1	50-70	580	530	380
KGPS--2T	1250	380	2000	2500	500	750	0.5-1	50-70	560	520	370
KGPS--2T	1250	660	1140	1430	880	1300	0.5-1	50-70	560	520	370
KGPS--3T	1500	380	2400	3000	500	750	0.5-1	50-80	530	510	350
KGPS--3T	1500	660	1370	1710	880	1300	0.5-1	50-80	530	510	350
KGPS--5T	2500	380	4000	3200	780	1170	0.3-1	60-90	510	490	340
KGPS--5T	2500	660	2272	2840	880	1300	0.3-1	60-90	510	490	340
KGPS--10T	5000	660	4560	5700	880	1300	0.3-1	70-100	500	450	320
temperature:1.Steel 1650°C 2.Iron 1450°C 3.Copper 1150 °C 4.Brass 1000 °C 5. Aluminum 700 °C

Remark:

1.Melting time and power consumption/ton is important to equipment power, raw material shape and weight, operator's skill level and other elements;

2.Configuration :an intermediate frequency power supply,a capacitor cabinet, an overturn control cabinet, body, two sets of reduction boxes and supports, two water cooling cables, etc

3.The above data is of standard model. We also provide customized non-standard products with different power or melting speed.
