Home > Products > Bottle Blowing Machine > Semi-Automatic Blowing Machine
Semi-Automatic Blowing Machine
US$ 1,000 - 10,000
/ Set
1 Set(Min. Order)
- shanghai port
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HuangYu | |
| Model Number | HY-B-1 |
Product Description
Specifications
This blowing bottle machine is suitable for producing PET/PE and PP plastic containers and bottle in all shapeMachine peculiarity:
- this machine can blowing 0.-2.0 l PET bottle.
- capacity:1000 pcs/h
- especial air deposited setting
- operation need one person, and don’t need some especial train
- debug and installation is very very easy
- finish product discard as useless ≤2%
Main technical parameter
sort | item | unit | Technical data | |
HY-B-1 |
| |||
Blowing machine | capacity | L | 2(2-cavity) 3(1-cavity) |
|
Theory capacity | pcs/h | 450-1000 |
| |
bottle caliber | mm | 15-75 |
| |
Mouding board size | mm | 350*450 |
| |
Allowable thicfness | mm | 120-280 |
| |
Movinr distance | mm | 150 |
| |
Working air pressure | Mpa | <=1.0 |
| |
Blowing air pressure | Mpa | <=4.0 |
| |
Blowing power | KW | 0.2 |
| |
weight | Kg | 800 |
| |
size | mm | 1360*600*1580 |
| |
oven | power | KW | 10 |
|
weight | Kg | 450 |
| |
size | mm | 1450*700*1150 |
| |
Contact Us
- Zhangjiagang Huanyu Beverage Machinery Co., Ltd.
- Contact nameMary Dou Chat Now
- Phone86-512-58536922
- AddressZhenbei Road Leyu Town, Suzhou, Jiangsu
