Home > Products > Other machines > DY-SAAM Small-size Air-auxiliary Road Marking Machine
DY-SAAM Small-size Air-auxiliary Road Marking Machine
- China Sea Port
- T/T
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | Dayu | |
| Model Number | DY-SAAM |
Product Description
Specifications
DY-SAAM Small-size Air-auxiliary Road Marking Machinetotal weight: 780kg
DY-SAAM Small-size Air-auxiliary Road Marking Machine
DY-SAAM Small-size Air-auxiliary Road Marking Machine is a high-tech road marking machine with
Micro-electronic control system which has multiple marking standard control modes, realizing the micro-
electronic intelligent control, and can adjust the standards according to the customer's needs.
Main feature of DY-SAAM Small-size Air-auxiliary Road Marking Machine
1.Single 60L glass beads bin with windows,Single or double glass beads spraying guns can be equipped on the left or right that can freely adjust its pressure, flow rate and spray width to ensure the spraying glass beads firmer evener and more economical.
2.The prepared high illuminating lamps provide convenience for the construction at night. The flash lights which can freely adjust the flicker frequency largely improve the safety in construction.
3.Operating conveniently.
Technical data for DY-SAAM Small-size Air-auxiliary Road Marking Machine
No. | Item | Technical Data |
1 | Engine | Imported Honda 20HP air-cooled gasoline engine |
2 | Spraying width | 100~450mm |
3 | Air compressor | 1m³/min displacement piston air pump with enough and stable pressurized air. |
4 | Glass beads spraying system | Single 60L glass beads bin with windows |
5 | Lighting and Warning function | Adjustable flicker frequency of flash lights. |
6 | Spray gun | Double new type pneumatic low pressure atomized air-auxiliary spray guns. |
7 | Paint tank | 200L with erect hydraulic stirring device in it. |
8 | Total weight | 780kg |
9 | Dimensions | 3400*2000*2400mm(L*W*H) |
