Home > Products > Mobile Asphalt Mixing Plant > Asphalt Mixer Drum Plant (20-100t/h)
Asphalt Mixer Drum Plant (20-100t/h)
- China Main Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | Dayu | Model Number | DHB | |
| Voltage | adjustable | Power(W) | adjustable | |
| Dimension(L*W*H) | adjustable | Weight | 40-100t | |
| Certification | CE,Gost,ISO9001,ISO14001 | Warranty | 18 months after install the plant, 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Asphalt Mixer Drum Plantoutput;20-100t/h
ISO9001,ISO14001,CE,Gost
Asphalt Mixer Drum Plant over 20 years
high-tech
Asphalt Mixer Drum Plant (20-100t/h)
Company Profile
Zhengzhou Dayu Machinery Co.,Ltd is a professional construction machinery manufacturer for Asphalt Mix Plant over 20 years. we are top 10 of China,
Dayu Asphalt Mixer Plant have three main groups
Asphalt Mixer Drum Plant
Asphalt Mixer Batch Plant
Asphalt Mixer Mobile Plant
Products:
Asphalt Mixer Drum Plant
The Components of Asphalt Mixer Drum Plant including Four Bin Feeder, Vibrating Screen System, Slinger Conveyor, Dryer Drum, Bitumen Tanks, Multicylone Exhaust, Load Out Conveyor, Mineral Filler, Control Cabin and Ldo Tank, which can working with good quality and high efficiency.
Integrated drying, heating and mixing in the whole part. DHB series mobile asphalt mixing plant can continuously produce asphalt mixture. Simple structure, reliable working, flexible moving and convenient maintenance.
Main Parameters of Asphalt Mixer Drum Plant DHBSeries
| Model | Productivity(t/h) | Weighing Accuracy | Total Power(kW) | Coal Consumption(kg/t) | |
| Aggregate | Asphalt | ||||
| DHB-20 | 20 | ±1.5% | ±1% | 40 | 10 |
| DHB-40 | 40 | ±1.5% | ±1% | 75 | 10-13 |
| DHB-60 | 60 | ±1.5% | ±1% | 128 | 10-13 |
| DHB-80 | 80 | ±1.5% | ±1% | 165 | 10-13 |
| DHB-100 | 100 | ±1.5% | ±1% | 200 | 10-13 |
Main Structure of Asphalt Mixer Drum Plant DHB Series
1 Cold aggregate supply system (mobile)
2 Middle filter
3 Drying drum (mobile)
4 Asphalt supply system
5 Electric control system
Asphalt Mixer Batch Plant
LB Asphalt Mixer Batch Plant mainly including: cold aggregate supply system, drum dryer, burning system, hot aggregate elevator, vibrating screen, weighing system, mixing tower, dust collecting system, filler supply system, bitumen supply system, electronic control system, finished asphalt storage bin…
Dust Collecting System:
I. First grade gravitational dust collector + Second baghouse dust collector;
II. First grade gravitational dust collector + Second water dust collector.
Burning System:
I. Oil burning system; II. Gas burning system; III. Coal burning system; IV. Oil & Gas dual purpose burning system.
Finished Asphalt Storage Bin:
I. Integrated asphalt storage bin; II. Separated asphalt storage bin.
Capacity: 40-400t/h.
Main Parameters of Asphalt Mixer Batch Plant
| Type | Plant Capacity (standard conditions): | Mixer Capacity: | Consumption (standard conditions): | Measurement accuracy | |
| Fuel Oil | Fuel Coal | ||||
| LB500 | 40 t/h | 500 kg | 5.5-7 kg/t | 10kg/t | Aggregate: ±0.5% Powder: ±0.5% Asphalt: ±0.25% |
| LB700 | 56 t/h | 700 kg | 5.5-7 kg/t | 10kg/t | |
| LB800 | 64 t/h | 800 kg | 5.5-7 kg/t | 10kg/t | |
| LB1000 | 80 t/h | 1000 kg | 5.5-7 kg/t | 10kg/t | |
| LB1100 | 90 t/h | 1100 kg | 5.5-7 kg/t | 10kg/t | |
| LB1200 | 100 t/h | 1200 kg | 5.5-7 kg/t | 10kg/t | |
| LB1250 | 105 t/h | 1250 kg | 5.5-7 kg/t | 10kg/t | |
| LB1500 | 120 t/h | 1500 kg | 5.5-7 kg/t | 10kg/t | |
| LB1600 | 130 t/h | 1600 kg | 5.5-7 kg/t | 10kg/t | |
| LB2000 | 160 t/h | 2000 kg | 5.5-7 kg/t | 10kg/t | |
| LB2200 | 175 t/h | 2200 kg | 5.5-7 kg/t | 10kg/t | |
| LB2500 | 200 t/h | 2500 kg | 5.5-7 kg/t | 10kg/t | |
| LB3000 | 240 t/h | 3000 kg | 5.5-7 kg/t | 10kg/t | |
Our Service
Quality Control (QC):
Third Control
ISO9001:2000 Certificate
European CE Certificate
Environment Protection Design
Commercial Term:
Delivery Time : 30~40 Working Days
Payment Term : T/T or L/C
Transportation : by sea or railway in container.
After Sale Service:
Turn-Key Solutions
Erection & Commissioning Service
Operation Training Service
Spare Parts Supply (all working life)
Warranty Period ;12 months since delivery the machine .
More information can be get by contact with Zhengzhou Dayu Machinery Co.,Ltd
