4 in 1 MPEG-2 Super Encoder digital catv digital headend

FOB Price

USD $1 - $10,000 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Sichuan, China		Brand Name	SHIDA
Model Number	SDC-3000E

MPEG-2 Encoder( with SDI)
4*CVBS video inputs
4 pairs of unbalanced audio inputs

Product Description

Features

1 Supports MPEG-2 MP@ML(4:2:0) video encoding, and advanced video pre-treatment2

2 Supports MPEG-4 SP/ASP video encoding format

3 The audio formats are MPEG-1 Audio Layer2,AAC,AC3( optional)

4 Four CVBS video input

5 Four pairs of unbalance stereo audio input

6 Multiplexes one ASI input

7 Supports PAL,NTSC SD signal

8 Supports D1,HD1,2/3D1,3/4D1 resolution

9 Supports MPTS output

10 Keyboard and LCD operation

11 Support NMS operation

Speicification

Input	4 CVBS inputs , BNC interface
	4 pairs unbalanced stereo audio input, BNC interface
	1 ASI stream input, BNC interface

Video	Resolution	720×480_60i, 544×480_60i,352×480_60i 320240_60i ,176240_60i, 176*120_60i
		720×576_50i ,704576_50i,640576_50i, 320288_50i, 176288_50i, ,176*144_50i
	Encoding	MPEG-2 MP@ML MPEG-4 SP/ASP
	Chroma Format	4:2:0
	Bit-rate	0.8Mbps~20Mbps each channel
	Rate Control	CBR/VBR
	GOP Structure	IBBP
	Advanced Pretreatment	De-interlacing, noise reduction, sharpening
	Encoding	MPEG-1 Audio Layer 2,AAC,AC3
	Sampling rate	48KHz,44.1KHz,32KHz
	Resolution	24-bit
	Bit-rate	32Kb/s—384Kb/s each channel

Multiplexing		1 ASI input multiplexed with local 4 channels TS
Stream output		2-way ASI output, BNC interface
System function		LCD/keyboard, network management, Chinese and English language
		Ethernet software upgrade
Miscellaneous	Dimension (W× L× H)	482mm×410mm×44mm
	Approx weight	2.8kg
	Environment	0~45°C(work);-20~80°C(Store)
	Power	AC 100~240V±10%,50/60Hz
