MPEG-2 IP Encoder

FOB Price

USD $1 - $10,000 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

SHIDA

Model Number

SDC-3000E

MPEG-2 Encoder( with SDI)
analog and digital audio and video input interface
encoder SD audio & video MPEG2 format

Product Description

MPEG-2 IP Encoder

Input	Video	Analog composite video(CVBS), BNC interface
		S-Video interface
		SD-SDI, BNC interface
	Audio	Analog stereo audio(balanced), XLR interface
		Analog stereo audio(unbalanced), BNC interface
		AES / EBU digital audio, XLR interface
		SD-SDI embedded audio
Video	Resolution	720×480_60i, 720×576_50i(D1)
		544×480_60i, 544×576_50i(3/4D1)
		352×480_60i, 352×576_50i(HD1)
		480×480_60i, 480×576_50i(2/3D1)
	Encoding	MPEG-2 MP@ML(4:2:0)
	Bit-rate	0.8Mbps~20Mbps
	Rate Control	CBR/VBR
	GOP Structure	IBBP
	Advanced Pretreatment	De-interlacing, noise reduction, sharpening
Audio	Encoding	MPEG-1 Layer 2
	Sampling rate	48KHz,44.1KHz,32KHz
	Resolution	24-bit
	Bitrate	64Kb/s—384Kb/s
Stream output		2-way ASI output, BNC interface
Stream output		SPTS over UDP,10/100Base-T Ethernet interface (UDP unicast / multicast)
System function		LCD/keyboard, network management, Chinese and English language
System function		Ethernet software upgrade
General	Dimensions (WxDxH)	482mm×455mm×44.5mm
	Temperature range	0~45°C(operation), -20~80°C(storage)
	Power Requirements	AC 110V±10%,50/60Hz or AC 220V±10%,50/60Hz
