TESUNHO TH-UVF10 Dual Band Walkie Talkie With 0~9 Grades Squelch Level Setting
- Xiamen/Shenzhen/Hangzhou
- T/T Credit Card
You May Like
-
FDC FD-780 1500mAh Busy Channel Lockout 5w Walkie-talkie for Army
-
TS-6100 Red Small Portable Talkie With 9-level Sensitivity Adjustment
-
1600mAh Handheld TH-360 Transceiver Wholesale
-
TESUNHO TH-900 Exceptional Quality Small Modern Licence-free High Power Uhf Long Range Handheld Discount Two Way Radios
-
TH-900 Waterproof 8w Handheld Radio Vhf Uhf Walkie Talkie
-
20km Long Distance Customized 2 Way Radio TESUNHO Walkie Talkie TH-850PLUS UHF VHF Walky Talky
Product Details
| Place of Origin | Fujian, China | Brand Name | TESUNHO | |
| Model Number | TH-UVF10 | Type | Handheld | |
| Dimensions | 100 x 52 x 32 cm | Frequency Range | 70-108MHz(FM Receive only) & 136-174MHz & 245-246MHz & 400-520MHz | |
| Storage Channel | 2*128 | Talk Range | 3-10KM |
Product Description
TESUNHO TH-UVF10 Dual Band Walkie Talkie with
0~9 Grades Squelch Level Setting

Dual band, dual display, dual standby | A/B band independent operation |
128 groups channels storage | FM radio and 25 stations storage |
Wide/Narrow Band(25kHz/12.5kHz) | 0~9 grades VOX selectable |
Chinese/English voice prompt | CTCSS/DCS and scanning |
1750Hz tone | PTT & ANI ID |
Priority transmit selectable | 0~9 grades squelch level setting |
LED display mode | Keypad beeper setting |
Transmit over beeper | Dual watch/monitor |
Receive saving function | Auto keypad lock |
Power-on display | Battery power voltage |
Power-on message | Repeater offset function |
Channel name display and setting | Reapter shift direction |
VFO step function | Shortcut menu operation mode |
Emergency Alarm | DTMF encoder & decoder(optional) |
Remote skill/stun/activate(optional) | High/Low TX power selectable |
Busy channel lock-out(BCLO) | Transmitter time-out timer(TOT) |
Voice companding | Tri-color background light selectable |
PC programmable | Wire clone |

Item number | TH-UVF10 |
General | |
Frequency Range | 70-108MHz(FM Receive only) 136-174MHz 245-246MHz 400-520MHz |
Channel No. | 128*2 |
Frequency Stability | ±2.5ppm |
Antenna | High gain antenna |
Antenna Impedance | 50Ω |
Operating Voltage | DC 7.2V |
Mode of operation | Simple or semi-duplex |
Dimension(W x H x D) | 100 x 52 x 32 mm |
Weight | 250g(including battery, antenna) |
Transmitter | |
Output power | ≥4W(H) ≥0.5W(L) |
Modulation Mode | 16kΦF3E / 11kΦF3E |
Maximum deviation | <5kHz(Wide) / <2.5kHz(Narrow) |
Spurious Radiation | <7μW |
Adjacent Ch. power | ≤-65dB(Wide) / ≤-60dB(Narrow) |
Pre-emphasis characteristics | 6dB |
Current | ≤1.6A(5W) |
CTCSS/DCS deviation | 0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow) |
Intermediation sensitivity | 8-12mv |
Intermediation distortion | <10% |
Receiver | |
RF Sensitivity | -122dbm(12db SINAD) |
Audio power | ≥0.5W |
Audio Distortion | ≤10% |
Intermediation | ≤-65dB(Wide) / ≤-60dB(Narrow) |
Selectivity | ≤-65dB(Wide) / ≤-60dB(Narrow) |
Spurious Rejection | ≤-65dB |
Blocking | ≥85dBuv/m |

Professional | 10 years Electronics Design Experience. Powerful and reliable R&D team. |
Effective | Instant respond to customer's enquiry. Control design and productive cost,cost-effective. |
Trusted | Never reveal customers design. Exclusivity is guaranteed! |
To-be-perfect | Because of all the above. |
Target Customer | Who has distinctive foresight on the industry. Who wants to save the high expenses on R&D in order to enhance integrated competition. Whole sellers who has a large local market and wants its own brand. |
Warranty:
Item | Period | Service |
Main Unit | 2 Years Warranty | finish maintainance within 1-15days after receiving the returned units |
Battery | Half Year Warranty | Within Half Year:send you brand new one if it is not manually damaged; Beyond Half Year:supply cost-effective renovation |
Charger | Half Year Warranty | Within Half Year:send you brand new one if it is not manually damaged; Beyond Half Year:supply cost-effective renovation |
