solar cable / UL certified 20AWG
US$ 0.98 - 1.12
/ Meter
5000 Meters(Min. Order)
- Shenzhen
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Haerkn | |
| Model Number | UL PV WIRE 10AWG | Type | Other, double insulated | |
| Application | Other, Connection wiring for solar PV power system and PV inverter, and so on | Conductor Material | Other, Tinned copper | |
| Conductor Type | Stranded | Insulation Material | Other, XLPE , XLPE |
Product Description
Specifications
1. UL & ROHS compliant2. FEP insulated
3. 600V & -40~+90 deg C
4. Tinned copper
5. Dry, Wet, Sun resistant
UL PV WIRE 10AWG Specification
- Rated temperatur: 90°C
- Rated Voltage: 600V
- Color: White, Red, Black, Blue, Yellow, Green, Brown, Pink or other (no transparent)
- Conductor: Tinned copper 84/0.30 stranded 3.18±0.1mm
- Inner Insulation: XLPE, thickness: 0.92~1.14mm
- Inner Dia.: 5.5±0.15mm
- Outer Insulation: XLPE black, thickness: 0.57~0.76mm
- Outer Dia.: 7.1±0.25mm
- Application: Connection wiring for solar PV power system and PV inverter, and also can be used as underground feeder cable.
- Reference Standard: UL4703/UL44
Electrical Characteristics:
- Max DC Conductor Resistance at 20°C (Ω/km): 3.73
- Min. Insulation DC Resistance(Mohm.km): 10.0
- Dielectric Strength(KV/min): AC3.0
Mechanical Characteristics:
Test Object: Insulation
- Test Material: XLPE
- Before Tensile Strength (N/mm2) ≥1.05
- Aging Elongation (%) ≥150
- Aging Condition (°C) 121±1°C×168H
- After Tensile Strength (N/mm2) ≥70% of original
- Aging Elongation (%) ≥70% of original
Test Object: Jacket
- Test Material: XLPE
- Before Tensile Strength (N/mm2) ≥1.05
- Aging Elongation (%) ≥150
- Aging Condition (°C) 110±1°C×168H
- After Tensile Strength (N/mm2) ≥70% of original
- Aging Elongation (%) ≥70% of original
