Home > Products > Pressure Oil Purifier > LY Efficient Plate Pressure Oil Filter
LY Efficient Plate Pressure Oil Filter
- CHONGQING PORT
- T/T Money Gram
You May Like
Product Details
| Condition | New | Place of Origin | Chongqing, China | |
| Brand Name | JUNNENG | Model Number | LY | |
| Weight | depends onactual modle | Dimension(L*W*H) | depends on actual modle | |
| Certification | CE; ISO9001; Bureau Veritas | Warranty | 1 year |
Product Description
LY Efficient Plate Pressure Oil Filter
LY Efficient plate pressure oil filter is mainly used to separate the impurities and water from the oil. It is suitable for filtering the cooking oil, transformer oil, used lubricating oil and so on. There is filtering media, such as filtering paper or filtering cloth, installed between the plastic filter board and filter plate that will be fixed to form a single filtering room under the pressure of the packing device. The filtering paper or filtering fuse packed between the filter board and filter plate will play a role of filtering. It's characterized by simple structure, easy operation, low cost.
Technical Parameters
Model | LY-30 | LY-50 | LY-100 | LY-125 | LY-150 | LY-200 | LY-300 |
Flow(L/min) | 30 | 50 | 100 | 125 | 150 | 200 | 300 |
Vacuum Range(MPa) | 0~0.5 | ||||||
Filter Area (m2) | ≥0.8 | ≥1.0 | ≥1.3 | ≥1.54 | ≥2.18 | ≥2.5 | ≥3.1 |
Plate size (mm) | 300×300 | ||||||
Way for compressing | Manual spiral pressure | ||||||
Number of filter box | 11 | 13 | 17 | 23 | 27 | 34 | 41 |
Number of plate | 12 | 14 | 18 | 25 | 28 | 35 | 42 |
Power supply | 380V 50HZ | ||||||
Total Power (KW) | 1.1 | 1.5 | 2.2 | 2.2 | 3 | 4 | 5.5 |
Revolving speed(r/min) | 1440 | ||||||
Filter precision (μm) | ≤5 | ||||||
Plate size (mm) | 300*300 | ||||||
inlet (outlet) diameter(mm) | φ25 | φ32 | φ42 | φ42 | φ50 | φ50 | φ60 |
L(mm) | 750 | 800 | 820 | 850 | 880 | 920 | 1000 |
W(mm) | 420 | 450 | 500 | 550 | 550 | 600 | 600 |
H(mm) | 750 | 800 | 930 | 1100 | 1100 | 1100 | 1100 |
Weight(kg) | 80 | 95 | 130 | 180 | 210 | 250 | 300 |
Dimension and weight will be changed with changing the technical specification.
