Supply JL Portable-type Automatic Oil Purifier

FOB Price

US$ 800 - 2,000 / Set

1 Set(Min. Order)

Port Chongqing or Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Flow	30-200 L/Min
Working Pressure	Normal Pressure	Place of Origin	Chongqing, China
Brand Name	JunNeng	Model Number	JL
Usage	Other, all kinds of waste oil	Voltage	220~415V
Power(W)	1.1-5KG	Dimension(LWH)	Pack
Weight	200-1600KGS	Certification	ISO9001
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Usage:
----This machine is fit for oil-using departments and corollary equipments. It can be used in the filtration of mechanical impurity, high-lift and long-distance oil pumping and injection.

Characteristics:
----This type of machine filters by three steps whose filtering elements gradually become intensive.It doesnt need filter paper with several advantages such as:portable,easy-handling and environment protecion .etc. It can not only filter the impurities in oil ,but also satisfy the high-lift and long-distance oil pumping and injection.
Technical Parameters

Model		JL-30	JL-50	JL-70	JL-100	JL-150	JL-200	JL-250	JL-300
L/min Flow		30	50	70	100	150	200	250	300
Lift		5m	8m	8m	10m	12m	15m	15m	15m
Filter precision		5µm	5µm	5µm	5µm	5µm	5µm	5µm	5µm
kw Total Power		0.55	0.75	1.1	2.2	3	3	4	4
Power		50HZ 380V
/inlet (outlet) diameter
mm Dimension	L	560	650	650	700	700	800	800	800
	W	450	500	500	550	550	580	580	580
	H	450	500	500	550	550	580	580	580

Dimension and weight will be changed with changing the technical specification

If you want to know more information about these series, please contact us.

Our products include:

Series of RZL Lubricating Oil Purifier

Series of RZL-B Lubricating Oil Purifier

Series of ZLA Two-Stage Vacuum Oil Purifier

Series of ZL High-Efficient Vacuum Oil Purifier

Series of TZL Turbine Oil Purifier

Series of ZLC Two-Stage Multi-Function Vacuum Oil Purifier

Series of ZSC Engine Oil Purifier

Series of KL Phosphate Ester Fire-Resistant Oil Filter Machine

Series of TLA Light Fuel Oil Purifier

Series of LY Plant Pressure Oil Filtering Machine

Series of JL Portable-Type Oil Purifier
