Supply JL Portable Oil Filtration Unit/oil Purifier/oil Filter

FOB Price

US$ 800 - 2,000 / Set

1 Set(Min. Order)

Port chongqing or shanghai
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Chongqing, China		Brand Name	JunNeng
Model Number	JL-70		After-sales Service Provided	No overseas service provided

Product Description

JL portable oil filtration unit can be used in the filtration of mechanical impurity, high-lift and long-distance oil pumping

Usage:
----This machine is fit for oil-using departments and corollary equipments. It can be used in the filtration of mechanical impurity, high-lift and long-distance oil pumping and injection.

Characteristics:
----This type of machine filters by three steps whose filtering elements gradually become intensive.It doesnt need filter paper with several advantages such as:portable,easy-handling and environment protecion .etc. It can not only filter the impurities in oil ,but also satisfy the high-lift and long-distance oil pumping and injection.
Technical Parameters

Model		JL-30	JL-50	JL-70	JL-100	JL-150	JL-200	JL-250	JL-300
L/min Flow		30	50	70	100	150	200	250	300
Lift		5m	8m	8m	10m	12m	15m	15m	15m
Filter precision		5µm	5µm	5µm	5µm	5µm	5µm	5µm	5µm
kw Total Power		0.55	0.75	1.1	2.2	3	3	4	4
Power		50HZ 380V
/inlet (outlet) diameter
mm Dimension	L	560	650	650	700	700	800	800	800
	W	450	500	500	550	550	580	580	580
	H	450	500	500	550	550	580	580	580

Dimension and weight will be changed with changing the technical specification
