Outdoor High Voltage Isolator Siwtch GW9-10W
Negotiable
/ Piece
100 Pieces(Min. Order)
- ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | HAIVOL | |
| Model Number | GW9-10W | Max. Current | 630A | |
| Max. Voltage | 12KV |
Product Description
Specifications
Outdoor High Voltage disconnect siwtch1.Rated voltage:12KV
2.long life time
3.Widely sold in nearly 50 countries
Outdoor High Voltage disconnect siwtch
GW9-10W
The "GW9-10W"type of outdoor high voltage isolator switch is the high voltage switch equpment of single phase AC 50Hz.The prducts is suitable for power system with rated voltage 12KV to make or break power supply under circumstances of with voltage and nomload.
The isolator is adopts islated hook rod to operate.
Technical Specification:
| Type | Rated voltage (KV) | Rated current (A) | 4S Heat steady e.c | Shock voltage (A) | Impulse withstand voltage | Power-frequency withstand voltage | ||
| Relatively earth | Between fracture | Relatively earth | Between fracture | |||||
| HGW9-10W/200 | 12 | 200 | 12500 | 31500 | 75 | 85 | 38 | 42 |
| HGW9-10W/400 | 12 | 400 | 12500 | 31500 | 75 | 85 | 38 | 42 |
| HGW9-10W/630 | 12 | 630 | 12500 | 31500 | 75 | 85 | 38 | 42 |
| HGW9-10W/1000 | 12 | 1000 | 12500 | 31500 | 75 | 85 | 38 | 42 |
