Outdoor Gang Isolator Switch 11kv / 33kv
US$ 160 - 260
/ Set
10 Sets(Min. Order)
- ningbo
- T/T
You May Like
-
Outdoor Pole Mount Type SF6 Gas Insulated Load Break Switch
-
Outdoor Expulsion Drop-out Type Distribution Fuse Cutout Series
-
Outdoor Expulsion Drop-out Type Distribution Fuse Cutout Series
-
Outdoor Expulsion Drop-out Type Distribution Fuse Cutout Series
-
Outdoor Expulsion Drop-out Type Distribution Fuse Cutout Series
-
Outdoor Expulsion Drop-out Type Distribution Fuse Cutout Series
Product Details
| Place of Origin | Zhejiang, China | Brand Name | HAIVOL | |
| Model Number | RH-B-11/33KV | Max. Current | 400/600A | |
| Max. Voltage | 11/33KV |
Product Description
Specifications
Outdoor Gang Isolator Switch1.Rated voltage:11/33KV
2.Rated current:400/600A
3.Standard:IEC60964:1996/IEC62271-102:2002
Outdoor Gang Isolator Switch Model RH-B-11/33kV
Outdoor AC Gang isolator switch 11kv/400A-33kv/600A used in 3 phase AC 50/60Hz power circuit, it is used as switching on and switching off at the voltage with no load. It apply to IEC standard. IEC60964: 1996, IEC62271-102: 2002.
Technical Specification
| Type | Rated voltage (KV) | Rated current (A) | 4S Heat steady e. c. A | Impulse withstand voltage A | Impulse voltage | Power frequency withstand voltage | ||
| To earth (KV ) | Across the | To earth (KV ) | Across the isolating distance(KV) | |||||
| RH-B | 11 | 400 | 12500 | 31500 | 75 | 95 | 38 | 42 |
| 33 | 600 | 12500 | 31500 | 170 | 195 | 70 | 80 | |
Outline dimension
