stainless steel 1 4 ball valve
Negotiable
/ Piece
1 Piece(Min. Order)
- Shanghai
- T/T
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Ball | |
| Pressure | Medium Pressure | Power | Manual | |
| Material | Stainless Steel | Temperature of Media | Medium Temperature | |
| Media | Water | Port Size | 1/4"-4" | |
| Place of Origin | Shanghai, China | Brand Name | Changhao |
Product Description
1 pc ball valve
1-PC STAINLESS STEEL BALL VALVES. REDUCED PORT. 1000 WOG
Thread End : BSPT, NPT, DIN259, DIN2999
Materials : ASTM A351-CF8M
1-PC STAINLESS STEEL BALL VALVES. REDUCED PORT. 1000 WOG
Thread End : BSPT, NPT, DIN259, DIN2999
Materials : ASTM A351-CF8M (DIN 1.4408) Stainless steel ASTM A351-CF8(DIN 1.4308) Stainless Steel
- For chemical and industrial application.
- High quality investment casting body and caps.
- Pressure temperature rating :
- 1/4" - 4" 1000 PSI (PN63) / 450deg. F
- 15% reinforced glass fibrous Teflon seats
- Blow-out proof stem S/S 316, adjustable stem packing.
- 100% tested air-under water at at 100 PSI (6 Bars) open & close position.
OPTIONS : Padlocking device, butterfly & oval handle, 25% glassfibre R-PTFE seats.
