Home > Products > Marine Auxiliary Machinery > HIgh Quality Marine Sewage Treatment Plant
HIgh Quality Marine Sewage Treatment Plant
- Shanghai or Ningbo
- T/T
You May Like
Product Details
| Place of Origin | Chongqing, China | Brand Name | PP Marine | |
| Model Number | WCX |
Product Description
Specifications
Marine Sewage Treatment Plant1,small size
2,light weight
3,compact structure
Sewage Treatment Plant-WCX
This device adopts physical and chemical method to treat ship's domestic sewage. The structure type and technical performance is designed and manufactureed according to GIB2957-97 marine sewage treatment system general specification, while satisfies the requirement of IMO.resolution MEPC.159 (55). this device has characteristics of small size, light weight and compact structure, especially suitable for small installation space room or small ships. The discharged water after the treatment of the device has reached the effluent standard stipulated internationally, and it accords with the requirement of resolution MEPC.159 (55) of IMO environment protection commission, and international waste fluid effluent standard.
| Type | WCX |
| Suitable Number of People | 6 to 72 |
| Treatment Load (m3/D) | 0.67 to 8 |
| Organic Load (Kg/D) | 0.3 to 3.6 |
| Discharge Standard | SS≤35mg/L, BOD5≤25mg/L, Coli≤100/100mL,PH 6-8.5 |
Principle:
Under gravity,the sewage flows to the equipment and disposes most of the organic substance in the dirty water first,then flow to the second oxygen box, the sediment tank and disposes the dirty mud,next it flows to sterilizer,finally flows out through discharge pump.
| Type | WCX2 | |
| Capacity | average (L/D) | 1540 to 21700 |
| number of people | 20 to 300 | |
| organic load (Kg/D) | 0.77 to 10.9 | |
| Dry Weight (Kg) | 1.5 to 8.1 | |
| Wet Weight (Kg) | 3.8 to 35.8 | |
| Power (Kw) | 2.2 to 7.2 | |
Certificate:
Approved by ABS/LR/BV/NK/DNV/RINA/RS/IRS/CCS etc.
