32 Channel 720P Professional 2U HDCVI DVR

Model

HCVR5824S

System

Main Processor

Embedded processor

Operating System

Embedded LINUX

Video

Input

24 channel, BNC

Standard

NTSC(525Line, 60f/s), PAL(625Line, 50f/s)

Audio

Input

32 channel, BNC

Output

1 channel, BNC

Two-way Talk

1 channel Input,1 channel Output, BNC

Display

Interface

2 HDMI, 1 VGA, 1 TV

Resolution

1920×1080, 1280×1024, 1280×720, 1024×768, 800×600

Display Split

1/4/8/9/16/25/36

Privacy Masking

4 rectangular zones (each camera)

OSD

Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Recording

Video/Audio Compression

H.264/G.711

Resolution

720P(1280×720)/960H(960×576/960×480)/D1/4CIF(704×576/704×480) /CIF(352×288/352×240)/QCIF(176×144/176×120)

Record Rate

Main Stream:

720P/960H/D1/HD1/2CIF/CIF(1~25/30fps)

Extra Stream

CIF/QCIF(1~25/30fps)

Bit Rate

48~8192Kb/s

Record Mode

Manual, Schedule(Regular(Continuous), MD), Stop

Record Interval

1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection & Alarm

Trigger Events

Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips

Video Detection

Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank

Alarm Input

16 channel

Relay Output

6 channel

Playback & Backup

Sync Playback

1/4/8/16

Search Mode

Time/Date, MD & Exact search (accurate to second)

Playback Functions

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom

Backup Mode

USB Device/eSATA Device/Internal SATA burner/Network

Network

Ethernet

2RJ-45 port (10/100M/1000M)

Network Functions

HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter

Max. User Access

128 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Storage

Internal HDD

8 SATA ports, up to 32TB

External HDD

1 eSATA port, up to 16TB

Auxiliary Interface

USB Interface

4 ports (2 Rear), USB2.0

RS232

1 port, For PC communication & Keyboard

RS485

1 port RS485 for PTZ control,1 port RS422 for Keyboard

General

Power Supply

AC 100~240 V, 50/60 Hz

Power Consumption

40W

Working Environment

-10°C ~+55°C / 10%~90%RH / 86~106kpa

Dimension(W×D×H)

2U, 440mm×460mm×89mm

Weight

6.5KG(without HDD)
