Great Wall Mobile Small Crushing and Screening
- Shanghai Qingdao Tianjin
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Other, Portable Stone Crusher | |
| Application | Mining,Building Material,Metallurgy,Chemical Industry. | Motor Type | AC Motor | |
| Power(W) | 70000-297000 | Capacity(t/h) | 15-450 | |
| Place of Origin | Henan, China | Brand Name | Great Wall | |
| Model Number | Y3S/YG Series Mobile Stone Crusher | Dimension(L*W*H) | 10500*2800*3700~17000*3100*5800(mm) | |
| Weight | 25-81(t) | Certification | ISO9001:2008 | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Great Wall Mobile Small Crushing and Screening.1Simple Structure
2Easy Operation
3Super Quality
4CQC:ISO9001:2008.
Portable Crusher,Portable Stone Crusher,Movable Crusher.
"Great Wall Make Great Machine"
Different Colors&Packages are available
ISO9001:2008 Approved,For test report details,pls contact "GreatWall"
Portable Crusher,Portable Stone Crusher,Movable Crusher

The Portable stone crusher plant is not limited by the crushing place, and reduces high material transportation cost. It can crush materials on site or working nearly. It is widely used in the industry of mining, metallurgy, building materials, traffic, water conservancy and so on.

1.Move easily. It can go to the crushing place directly. It can move not only on the smooth road, but also on the bumpy road.
2.Compact structure and simple operation. Integrative equipment group with trailer save the working area. With generator, motor and control box on the trailer, it can work outdoor easily. Equipped with supporting facilities, it can be installed quickly and conveniently.
3.Save the cost. By crushing the materials on site, the transportation cost is reduced.
4.Wide applicability. The crushing plant can work as independent unit or work with other units to form a primary-secondary crushing system or primary-secondary-fine crushing system. It can also work as a production line with the screening equipment according to the requirement of customers (firstly screening then crushing, or firstly crushing then screening.)
5.Stable performance and convenient maintenance. Equipped with crushers, vibrating feeders, and vibrating screens designed by Great Wall Heavy Industry Machinery, the mobile crushing plant shows high quality and reliable performance. Materials are delivered by belt conveyors, which is simple to operate and easy to maintain. The machine is featured by low investment and high production efficiency.
6.Flexible configuration. It can be customized according to customers’ requirement on working site, materials and particle shape. Examples of customized machines include single units, combined units, units with self-discharged belt conveyors.

Portable Imapct Stone Crusher Main Specifications
Model | Vibrating screen | Impact crusher | Belt conveyor | Configuration of? wheels | Capacity | Overall Dimension | Weight |
Y3S1548F1010 | 3YZS1548 | PF1010 | B650×7M | Dual-axle | 50-80 | 12700×2800×5700 | 35 |
Y3S1848F1210 | 3YZS1848 | PF1210 | B650×7M | Dual-axle | 70-130 | 13500×3150×6000 | 41 |
Y3S1860F1214 | 3YZS1860 | PF1214 | B800×8M | Tri-axle | 90-180 | 15500×3150×6400 | 46 |
Y3S2160F1315 | 3YZS2160 | PF1315 | B800×8M | Tri-axle | 120-250 | 16200×3500×6700 | 57 |
Portable Jaw Stone Crusher Main Specifications
Model | Vibrating feeder | Jaw crusher | Belt conveyor | Configuration of wheels | Capacity | Overall Dimension | Weight |
YG725E46 | GZD750×2500 | PE400×600 | B650×7M | Single-axle | 15-60 | 10500×2800×3700 | 25 |
YG938E57 | GZD960×3800 | PE500×750 | B650×7.5M | Dual-axle | 40-100 | 13000×2900×4100 | 32 |
YG938E69 | GZD960×3800 | PE600×900 | B800×8M | Dual-axle | 60-140 | 13200×2900×4600 | 42 |
YG1142E710 | GZD1100×4200 | PE750×1060 | B1000×9M | Tri-axle | 80-230 | 15000×2900×5700 | 55 |
YG1349E912 | GZD1300×4900 | PE900×1200 | B1200×11M | Quad-axle | 140-320 | 17000×3100×5800 | 81 |
Portable Cone Stone Crusher Main Specifications
Model | Vibrating screen | Cone crusher | Belt conveyor | Configuration of wheels | Capacity | Overall Dimension | Weight |
Y3S1548Y900 | 3YZS1548 | PY900 | B650×7M | Dual-axle | 30-90 | 13700×2800×5700 | 34 |
Y3S1848S36 | 3YZS1848 | CZS36 | B650×7M | Dual-axle | 45-165 | 13700×3150×5700 | 39 |
Y3S1860S51 | 3YZS1860 | CZS51 | B800×8M | Tri-axle | 80-350 | 15200×3150×6400 | 55 |
Y3S2160H220 | 3YZS2160 | HP220 | B1000×8M | Tri-axle | 100-430 | 15200×3500×6450 | 57 |

1.Pre-sales Service
Offering comprehensive technical and business consultation services;
Proposing th e most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technician.
2.After-sales Service
Highly inspecting equipments in every working procedure, quality comes first;
Fast & Safe Delivery;
Assisting our clients for foundation construction of equipments;
Dispatching engineers to install and debug equipments;
Training the first-line operators on site;
Regularly visit clients to solve production problems;
Providing life-long maintenance service;
Providing technical exchanging;

With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.
Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.
Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
"persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.
With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.
During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.
Do not hesitate send us inquiry for more details about the Mobile Small Crushing and Screening .
