Great Wall Portable Impact Crushing Plant(ISO9001:2008)
- Qingdao Tianjin Shanghai
- T/T
You May Like
Product Details
| Condition | New | Type | Other, Stone Crushing Line | |
| Application | Mining,Building Material,Metallurgy,Chemical Industry. | Motor Type | AC Motor | |
| Power(W) | As required | Capacity(t/h) | 30-500 | |
| Place of Origin | Henan, China | Brand Name | Great Wall | |
| Model Number | Stone Crushing Plant | Dimension(L*W*H) | 10500*2800*3700~17000*3100*5800 (mm) | |
| Weight | 25-81(t) | Certification | ISO9001:2008 | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
"Great Wall Make Great Machine"
Whole Set of Stone Making Line are avaialble
Portable Impact Crushing Plant

The stone crusher plant is not limited by the crushing place, and reduces high material transportation cost. It can crush materials on site or working nearly. It is widely used in the industry of mining, metallurgy, building materials, traffic, water conservancy and so on.
Mobile Imapct Crushing Plant Main Specifications
impact crusher
impact crusher plant
Model | Vibrating screen | Impact crusher | Belt conveyor | Configuration of? wheels | Capacity | Overall Dimension | Weight |
Y3S1548F1010 | 3YZS1548 | PF1010 | B650×7M | Dual-axle | 50-80 | 12700×2800×5700 | 35 |
Y3S1848F1210 | 3YZS1848 | PF1210 | B650×7M | Dual-axle | 70-130 | 13500×3150×6000 | 41 |
Y3S1860F1214 | 3YZS1860 | PF1214 | B800×8M | Tri-axle | 90-180 | 15500×3150×6400 | 46 |
Y3S2160F1315 | 3YZS2160 | PF1315 | B800×8M | Tri-axle | 120-250 | 16200×3500×6700 | 57 |
Mobile Cone Crushing Plant Picture and Main Specifications
Model | Vibrating screen | Cone crusher | Belt conveyor | Configuration of wheels | Capacity | Overall Dimension | Weight |
Y3S1548Y900 | 3YZS1548 | PY900 | B650×7M | Dual-axle | 30-90 | 13700×2800×5700 | 34 |
Y3S1848S36 | 3YZS1848 | CZS36 | B650×7M | Dual-axle | 45-165 | 13700×3150×5700 | 39 |
Y3S1860S51 | 3YZS1860 | CZS51 | B800×8M | Tri-axle | 80-350 | 15200×3150×6400 | 55 |
Y3S2160H220 | 3YZS2160 | HP220 | B1000×8M | Tri-axle | 100-430 | 15200×3500×6450 | 57 |
Mobile Jaw Crushing Plant Main Specifications
Model | Vibrating feeder | Jaw crusher | Belt conveyor | Configuration of wheels | Capacity | Overall Dimension | Weight |
YG725E46 | GZD750×2500 | PE400×600 | B650×7M | Single-axle | 15-60 | 10500×2800×3700 | 25 |
YG938E57 | GZD960×3800 | PE500×750 | B650×7.5M | Dual-axle | 40-100 | 13000×2900×4100 | 32 |
YG938E69 | GZD960×3800 | PE600×900 | B800×8M | Dual-axle | 60-140 | 13200×2900×4600 | 42 |
YG1142E710 | GZD1100×4200 | PE750×1060 | B1000×9M | Tri-axle | 80-230 | 15000×2900×5700 | 55 |
YG1349E912 | GZD1300×4900 | PE900×1200 | B1200×11M | Quad-axle | 140-320 | 17000×3100×5800 | 81 |

1.Move easily. It can go to the crushing place directly. It can move not only on the smooth road, but also on the bumpy road.
2.Compact structure and simple operation. Integrative equipment group with trailer save the working area. With generator, motor and control box on the trailer, it can work outdoor easily. Equipped with supporting facilities, it can be installed quickly and conveniently.
3.Save the cost. By crushing the materials on site, the transportation cost is reduced.
4.Wide applicability. The crushing plant can work as independent unit or work with other units to form a primary-secondary crushing system or primary-secondary-fine crushing system. It can also work as a production line with the screening equipment according to the requirement of customers (firstly screening then crushing, or firstly crushing then screening.)
5.Stable performance and convenient maintenance. Equipped with crushers, vibrating feeders, and vibrating screens designed by Great Wall Heavy Industry Machinery, the mobile crushing plant shows high quality and reliable performance. Materials are delivered by belt conveyors, which is simple to operate and easy to maintain. The machine is featured by low investment and high production efficiency.
6.Flexible configuration. It can be customized according to customers’ requirement on working site, materials and particle shape. Examples of customized machines include single units, combined units, units with self-discharged belt conveyors.
Mobiel impact crusher working site picture
whole production line
Packaging & Shipping
The machine is fixed tightly when it is sent to the port by professionale truck. Before shipped, it is covered by waterproof material to avoid moisture and rough handling.
Services:
1.Pre-sales Service
Offering comprehensive technical and business consultation services;
Proposing th e most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technician.
2.After-sales Service
Highly inspecting equipments in every working procedure, quality comes first;
Fast & Safe Delivery;
Assisting our clients for foundation construction of equipments;
Dispatching engineers to install and debug equipments;
Training the first-line operators on site;
Regularly visit clients to solve production problems;
Providing life-long maintenance service;
Providing technical exchanging;
About Us:
With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.
Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.
Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
"Persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.
With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.
During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.
There are so many types mobile crushers, you may be puzzled at how to choose a right one. The following three questions can help you :
1. What is the raw material to be processed? And maximum feeding size of raw material?
2. What is the required output size after crushing?
3. How many tons per hour do you want?
With the answers looking up the specification, you will get the final answer. Or contract us, we will recommend the right one.
Do not hesitate send us inquiry for more details about the Great Wall Portable Impact Crushing Plant .
