Product Details
| Application | Liners Of Industrial Furnace | Thickness | 10-80mm | |
| Width | 1000/900/300mm | Length | 600/900/1000/1200mm | |
| Grade | ST (Standard) | Chemical Composition | AL2O3+SIO2 | |
| Working Temperature | 1000-1800 | Fiber Diameter | 2-3um | |
| Thermal Conductivity | 0.135 | Shrinkage (1800℉, 3h) | 1.1 | |
| Place of Origin | Henan, China | Model Number | Standard | |
| Brand Name | HENGRUI |
Product Description
Hengrui oven heat resistant insulation material is made by using Hengrui SGS certificate fibre board china supplier and a little binding agent through vacuum forming. Hengrui Fire resistance and Heat insulation ceramic fiber board can maintain its mechanical strength after high-temperature heating, and the board includes 6 levels: 1050℃, 1260℃, 1350℃, 1430℃, 1600℃, and 1700℃. Hengrui thermal insulation refractory plates can resist the scouring of airflow for its high strength, so it can be the material of internal linings.
The usability of oven heat resistant insulation material really good under the condition of high moisture. Hengrui oven heat resistant insulation material has excellent hyd-rophobicity after processing by specific techniques.
Hengrui oven heat resistant insulation material is made by using Hengrui ceramic fiber bulk and inorganic binding agent through vacuum forming. When using the board under the circumstance of high temperature, the pollution gas will not be generated.
◊Back-up lining of high-temperature industry furnaces.
◊Hot-face lining of ceramic kilns, heat-treatment furnaces and other industrial kilns.
◊Back-up and hot-face insulation materials for furnaces or aluminum industry.
◊Insulation material of Metallurgy,Machinery,Chemical,Optical,and environmental protection industries.
| oven heat resistant insulation material | HR1050
 | HR1260ST
 | HR1260HP
 |
 HR1350HA

 | HR1430Zr
 | HR1600 PMF | HR1700 PMF | |
| Classification Temperature(°C)
 | 1050 | 1260 | 1260 | 1350 | 1430 | 1600 | 1700 | |
| Density(KG/M3)

 | 250-350 | 250-350 | 250-350 | 320-400 | 320-400 | 400-550 | 400-550 | |
| Linear shrinkage%(24h) | ≤2.0 900°C | ≤2.0 1000°C | ≤2.0 1000°C | ≤2.5 1100°C | ≤3.0 1200°C | ≤1.5 1400°C | ≤1.5 1500°C | |
| Flexural strength(MPa)
 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.7 | ≥0.7 | |
| Thermal conductivity rate(W/m.k) | 400 °C | 0.08 | 0.084 | 0.084 | 0.084 | 0.084 | -- | -- |
| 600°C
 | 0.11 | 0.128 | 0.128 | 0.125 | 0.125 | 0.16 | 0.16 | |
| Chemical Composition(%) | Al2O3
 | 42-44 | 45-46 | 47-49 | 52-55 | 38-44 | ≥72 | ≥75 |
| Al2O3+SiO2
 | ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | ≥83 | ≥99.0 | ≥99.0 | |
| ZrO3 | - | - | - | - | 15-17 | - | - | |
| Other | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | |

We can provide free samples for customers
We can delivery goods quickly in 2-7 days
We can do OEM for trading company
