Home > Products > Ceramic Fiber Board > Heat Resistant Ceramic Insulation Plate
Heat Resistant Ceramic Insulation Plate
- CHINA PORT
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Application | Refractory | Thickness | 10-80mm | |
| Width | 1000/700/600 Mm | Length | 600/900/1000/1200mm | |
| Grade | HAZ (High Aluminum Zirconium) | Chemical Composition | AL2O3+ZrO3 | |
| Working Temperature | 1000-1800 | Fiber Diameter | 3-5um | |
| Thermal Conductivity | 0.135 | Shrinkage (1800℉, 3h) | 1.1 | |
| Place of Origin | Henan, China | Model Number | High Aluminum | |
| Brand Name | HENGRUI |
Product Description
Hengrui resistant ceramic insulation plate is made by using Hengrui ceramic fiber bulk and a little binding agent through vacuum forming. Hengrui ceramic fiber board can maintain its mechanical strength after high-temperature heating, and the board includes 6 levels: 1050℃, 1260℃, 1350℃, 1430℃, 1600℃, and 1700℃. Hengrui thermal insulation board, insulating boardcan resist the scouring of airflow for its high strength, so it can be the material of internal linings.
The usability of thermal insulation material for oven is really good under the condition of high moisture. Hengrui ceramic fiber board has excellent hyd-rophobicity after processing by specific techniques.
Hengrui thermal insulation material for oven, oven insulation material, ceramic fiber products is made by using Hengrui ceramic fiber bulk and inorganic binding agent through vacuum
forming. When using the board under the circumstance of high temperature, the pollution gas will not be generated.
resistant ceramic insulation plate | HR1050
| HR1260ST
| HR1260HP
|
HR1350HA
| HR1430Zr
| HR1600 PMF | HR1700 PMF | |
Classification Temperature(°C)
| 1050 | 1260 | 1260 | 1350 | 1430 | 1600 | 1700 | |
Density(KG/M3)
| 250-350 | 250-350 | 250-350 | 320-400 | 320-400 | 400-550 | 400-550 | |
| Linear shrinkage%(24h) | ≤2.0 900°C | ≤2.0 1000°C | ≤2.0 1000°C | ≤2.5 1100°C | ≤3.0 1200°C | ≤1.5 1400°C | ≤1.5 1500°C | |
Flexural strength(MPa)
| ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.7 | ≥0.7 | |
| Thermal conductivity rate(W/m.k) | 400 °C | 0.08 | 0.084 | 0.084 | 0.084 | 0.084 | -- | -- |
600°C
| 0.11 | 0.128 | 0.128 | 0.125 | 0.125 | 0.16 | 0.16 | |
| Chemical Composition(%) | Al2O3
| 42-44 | 45-46 | 47-49 | 52-55 | 38-44 | ≥72 | ≥75 |
Al2O3+SiO2
| ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | ≥83 | ≥99.0 | ≥99.0 | |
| ZrO3 | - | - | - | - | 15-17 | - | - | |
| Other | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | |
We can do OEM for trading company
