50mm Thick Roof Insulation Roll
- ANY CHINA PORT
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Cheap Heat Insulation Material
-
Aluminum Thermal Reflective Foil Insulation Blanket
-
Fireproof Wall Materials, Furnace Insulation Materials, Furnace Wall Lining Materials
-
Thermal Insulation Blanket, Oven Insulation Material, Duct Insulation
-
Heat Resistant Insulation Pipe Insulation Cladding
-
Fire Resistant Steam Pipe Insulation Material
Product Details
| Grade | COM (Common) | Application | Liners Of Industrial Furnace | |
| Thickness | 6-50mm | Width | 610/1220mm | |
| Length | 3600/7200/146400mm | Chemical Composition | AL2O3+SIO2 | |
| Working Temperature | 1050-1600 | Fiber Diameter | 3-5um | |
| Shrinkage (1800 ℉, 3h) | 3%(24 Hours) | Thermal Conductivity | 0.09-0.16 | |
| Model Number | 1050 | Brand Name | hengrui | |
| Place of Origin | Henan, China |
Product Description
Hengrui 50mm thick roof insulation roll is made of special ceramic fiber through double needle-punching processing. The double needle-punching techniques improve the degree of fiber intertexture, and the performance of delamination resistance as well as tensile strength. The blanket does not contain any bonding agent and with the characteristics of stable chemical performance, resistance to the erosion of most chemicals,The physical property like refractory and insulation keep same when meet with oil,water or steam.
◊ Internal and external lining for industry furnace.
◊ Internal and external insulation for Pipeline.
◊ Insulation for home application, nuclear power and aerospace .
◊ Joint sealing and filing insulation.
◊ Expansion seals/pipe coverings.
| 50mm thick roof insulation roll | HR1050 | HR1260ST | HR1260HP | HR1350 HA | HR1430 Zr | HR1600 PMF | |
| Classification Temperature(°C) | 1050 | 1260 | 1260 | 1350 | 1430 | 1600 | |
| Working Temperature(°C) | 900 | 1050 | 1050 | 1200 | 1250 | 1400 | |
| Density(KG/m3) | 96-160 | 96-160 | 96-160 | 96-160 | 96-160 | 96-160 | |
Liner Shrinkage (24h,128 Kg/M3) | ≤2.4 (900℃) | ≤2.3(1000℃) | ≤2.4 (1050℃) | ≤2.2 (1150℃) | ≤3 (1250℃) | ≤1.5 (1400℃) | |
Tensile Strength Kpa(128Kg/M3) | 40 | 80 | 80 | 80 | 80 | 100 | |
Thermal Conductivity Rate(128 Kg/M3 ,W/m.k) | 400 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | - |
| 800 | 0.16 | 0.16 | 0.16 | 0.16 | 0.16 | 0.16 | |
| 1000 | - | 0.23 | 0.23 | 0.23 | 0.21 | 0.20 | |
| Chemical Composition(%) | Al2O3 | 42-44 | 45-46 | 47-49 | 52-55 | 38-42 | 72-75 |
| Al2O3+SiO2 | ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | |
| ZrO3 | -- | -- | -- | -- | 15-17 | -- | |
| Other | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | |
We can provide free samples for customers
We can delivery goods quickly in 2-7 days
We can do OEM for trading company
