Home > Products > Asphalt Mixing Plant > China Wholesale Supplier Construction Material Asphalt Batching Machinery

China Wholesale Supplier Construction Material Asphalt Batching Machinery

FOB Price

US$ 300,000 - 1,200,000 / Set

1 Set(Min. Order)

Port XIAMEN CHINA
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Fujian, China
Brand Name	NFLG	Model Number	GLB1500;GLB2000;GLB3000;GLB4000;GLB5000
Voltage	220V	Power(W)	319-945kw
Dimension(LWH)	1600030004200mm	Weight	50-130t
Certification	CE, OHSAS18001, CQM, ISO9001,ISO14001	Warranty	12mouths
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

China wholesale supplier construction material asphalt batching machinery

Online Service

Price Service

Product Service

Technology Service

Product Description

The tower-type asphalt mixing equipment developed by NFLG provides a thermal efficiency of 90% and an energy reduction of 15%. The equipment uses the unique online intelligent detection. The burner independently developed by NFLG uses the double frequency conversion, various types of oil, and the original wear-resistant parts imported from Sweden which rank first in the world to provide safe, real-time and fast services.

1. Parameter for Asphalt Batching Machinery

Model	GLB1500	GLB2000	GLB3000	GLB4000	GLB5000
Capacity (under 5% aggregate moisture)	120 t/h	160 t/h	240 t/h	320 t/h	400 t/h
Cold aggregate hopper quantities	4	5	5	6	6
Volume	9 m³	9 m³	20 m³	20 m³	20 m³
Drying drum model	GT 120	GT 160	GT 240	GT 320	GT 400
Length/Diameter	7.5 m * 1.8 m	9 m * 2.25 m	10 m * 2.5 m	11 m * 2.8 m	12.5 m * 2.9 m
Fuel	Diesel, heavy oil, natural gas, liquefied petroleum gas	Diesel, heavy oil, natural gas, liquefied petroleum gas	Diesel, heavy oil, natural gas, liquefied petroleum gas	Diesel, heavy oil, natural gas, liquefied petroleum gas	Diesel, heavy oil, natural gas, liquefied petroleum gas
Dust Collecting Model	Gravity dust collector+ bag filter	Gravity dust collector+ bag filter	Gravity dust collector+ bag filter	Gravity dust collector+ bag filter	Gravity dust collector+ bag filter
No. of screen layers	4 layers	5 layers	5 layers	6 layers	6 layers
Screening area	17 m²	26 m²	40 m²	59 m²	77 m²
Hot aggregate hopper	20 m³	20 m³	36 m³	50 m³	70 m³
Aggregate scale	1600 kg	2250 kg	3250 kg	4250 kg	5250 kg
Powder scale	225 kg	260 kg	400 kg	600 kg	750 kg
Asphalt scale	190 kg	260 kg	300 kg	500 kg	600 kg
Mixer capacity	1500 kg/batch	2000 kg/batch	3000 kg/batch	4000 kg/batch	5000 kg/batch
Finished product hopper	60 t	70 t	80t	110 t	120 t

2. Characteristics for Asphalt Batching Machinery

Drying System

1. The system uses four world-renowned shaft-mounted motor reducers to easily and freely drive dry drums.
2. The optimized lifting blades provide more uniform heating and high heat utilization ratio.
3. The external roller of thermal insulation materials and coat of stainless steel effectively prevent avoid heat loss.
4. The drive drums and imported bearings undergoing careful calculation and heat treatment act long service life and reliable operation.
5. The patented new drying drums reduce energy consumption by 20% compared with the original ones.

Our Company

Established in 1991, Fujian South Highway Machinery Co., Ltd. (hereinafter referred to as NFLG) is a leading enterprise in the field of China’s mixing engineering machinery. NFLG possesses the fixed assets of over 190 million RMB, with over 1200 staff in total. NFLG is a professional international company focusing on the development, manufacturing and service of mixing plants and providing integrated solutions for the mixing plant industry chains. The main businesses of NFLG cover mining design, mining and crushing of construction materials, manufactured sand production lines, solid waster processing machinery and engineering mixing plant industry chains.

NFLG has already obtained 16 national science and technology progress prizes, 45 provincial science and technology progress prizes and several municipal or district-level science and technology progress prizes, together with 17 National Invention Patents, 204 National Utility Model Patents and 5 appearance patents.
