Hitachi Aluminium TIG Welder (GTAW)
- Ningbo/Shanghai China
- T/T Credit Card
You May Like
-
Cheap Mini AC/DC Tig Welder for Sale
-
Professional Aluminum AC/DC TIG Welder 500 Amp ac dc Tig Welding Machine
-
Professinal Esab High Frequency Ac/dc Tig Welding Machine
-
New Design TIG/MMA 200 Welding Machine
-
New Multi Fucntion AC/DC MMA&Pulse TIG Inverter Welding Machine(WSME Series)
-
Cheap Laser WSM200 Welding Machine Same as Giant
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | ANDELI Or OEM | Model Number | TIG-500AC | |
| Arc Current | 20-500A | Pulse Frequency | 50/60HZ | |
| Rated Duty Cycle | 60% | Motor Type | Other | |
| Dimensions | 610x329x660mm | Usage | Precision & industrial aluminium welding | |
| Voltage | 3PH~,380/400V | Power(W) | 32KVA | |
| Certification | CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Hitachi Aluminium TIG Welder (GTAW)
TIG-315AC/400AC/500AC
Features:
1) IGBT inverter system, Soft Switch technology.
2) Full Digital controlling system, 64 byte MCU inside.
3) High-power SIMENS IGBT module.
4) Perfect air-cooling system, Intelligent Ventilator Management.
5) 3 workding modes:AC TIG/ DC TIG/ MMA.
6) Embedded welding expert database, Flexible parameters adjustment.
7) Memory: Capable for storing 100 sets of user-defined parameters.
8) AC Bias(EP/EN) & AC Balance adjustable for precise welding.
9) 2T(STD)/4T(HOLD) control mode.
10) Heavy Duty for max loading, welding cable could be length to 100M.
11) Available to connect Foot Pedal(optional).
| Item No | TIG-315AC | TIG-400AC | TIG-500AC |
| Input Voltage | 3PH~,380/400V,50/60Hz | 3PH~,380/400V,50/60Hz | 3PH~,380/400V,50/60Hz |
| Rated Input Capacity | 12KVA | 16KVA | 32KVA |
| Max No-load Voltage | 60-80V | 60-80V | 60-80V |
| Rated Output Current Range | 20-315A | 20-400A | 20-500A |
| Rated Duty Cycle | 60% @ 315A | 60% @ 400A | 60% @ 500A |
| Pulse Frequency Range | 0.2-20Hz | 0.2-20Hz | 0.2-20Hz |
| Pulse Width Range | 1-100% | 1-100% | 1-100% |
| Current Up-slope Time | 0.1-10S | 0.1-10S | 0.1-10S |
| Current Down-slope Time | 0.1-15S | 0.1-15S | 0.1-15S |
| AC Frequency Range | 20-100Hz | 20-100Hz | 20-100Hz |
| AC Balance (SP Value) | -40 ~+40 | -40 ~+40 | -40 ~+40 |
| AC Bias (EP/EN) Value | -50~ +30 | -50~ +30 | -50~ +30 |
| Arc Force Adjusting | 1-10 | 1-10 | 1-10 |
| Gas Pre-flow/Retard Time | 0.1-15S | 0.1-15S | 0.1-15S |
| Dimension(LxWxH) | 610x325x709mm | 610x325x709mm | 610x325x709mm |
| Weight | 45KG | 53KG | 65KG |
Why not try one sample first?Choosing our products,give yourself maximum profit. Inquires are typically answered within 24 hours.
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
