Home > Products > TIG IGBT Welding Machine > Inverter Tig/mma 200 Welder
Inverter Tig/mma 200 Welder
- Ningbo/Shanghai China
- T/T Credit Card
You May Like
-
Hitachi Aluminium TIG Welder (GTAW)
-
Cheap Mini AC/DC Tig Welder for Sale
-
Professional Aluminum AC/DC TIG Welder 500 Amp ac dc Tig Welding Machine
-
Professinal Esab High Frequency Ac/dc Tig Welding Machine
-
New Design TIG/MMA 200 Welding Machine
-
New Multi Fucntion AC/DC MMA&Pulse TIG Inverter Welding Machine(WSME Series)
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | ANDELI Or OEM | Model Number | ANDELI-TIG-250Di | |
| Arc Current | 5-250A | Pulse Frequency | 50/60HZ | |
| Pilot Arc Current | 5-250A | Rated Duty Cycle | 60% | |
| Motor Type | Other, AC/DC Motor | Dimensions | 430x195x320mm | |
| Usage | Precision TIG welding | Voltage | 1PH ~ 220/230/240V | |
| Power(W) | 7.4KVA | Certification | CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Inverter Tig/mma 200 welder
Features:
1) IGBT inverter system, Soft Switch technology.
2) Full Digital controlling system, 32 byte MCU inside.
3) Memory: Capable for storing 10 sets of user-defined parameters.
4) 2 working modes: DC TIG/MMA.
5) HF Arc Start, Arc Force, Anti-Stick.
6) Heavy Duty:60%.
7) 2T/4T control mode, widly pulse adjustment.
8) Available to connect Foot Pedal(optional).
9) Over Heat, Over Current protection, Input voltage regular fits.
Item No. | ANDELITIG-200Di | ANDELITIG-250Di |
Input Voltage | 1PH ~ 220/230/240V 50/60Hz | |
Input Power Capacity | 7.4KVA | 7.4KVA |
No-load Voltage | 70V | 70V |
Output Current Range | 5-200Amp | 5-250Amp |
Rated Duty Cycle (40oC) | 60% 200Amp | 60% 250Amp |
Pulse Frequency Range | 0.2-20Hz | 0.2-20Hz |
Pulse Width Range | 1-100% | 1-100% |
Current Up-slope Time | 0.1-10S | 0.1-10S |
Current Down-slop Time | 0.1-15S | 0.1-15S |
ARC Force Adjusting | 1-10 | 1-10 |
Gas Pre-flow/Retard Time | 0.1-15S | 0.1-15S |
Dimension (LxWxH) | 430x195x320mm430x195x320mm | |
Weight (KG) | 15KG | 15KG |
Why not try one sample first?Choosing our products,give yourself maximum profit. Inquires are typically answered within 24 hours...
Our salesmen will reply your inquiry within 24 hours. Any order is welcome. If you like to be our agent in your country, we can give you any support on the technique & other aspects.
If you have any questions ,please contact with us...
