Low energy drying machine for sawdust biomass
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Drum Drying Equipment | |
| Place of Origin | Henan, China | Brand Name | Derry | |
| Model Number | TRM-1812 | Voltage | 380V 50HZ 3 PHASE | |
| Power(W) | 18kw | Dimension(L*W*H) | Dia18*Length12m | |
| Weight | 25T | Certification | ISO CE SGS | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
drying machine for sawdust biomass1.feed pellet dryer,
2.easy operation
3.large production capacity
4.CE,ISO,SGS
The Introduction Of drying machine for sawdust biomass
1.The drying machine for sawdust biomass is mainly used in buliding materials, metallurgy,
chemical plant,cement plant for drying of limestone slag, coal powder, slag, clay stone.
2.This drying machine for sawdust biomass is formed by rotary body, lifting blade, driving
device, supporting device and sealing ring.
3.During drying process, heat and weight (moisture content) transfer need to be finished
simultaneously, thus guaranteeing a higher moisture and water vapor partial pressure inside
the dryer than that outside the dryer, and guaranteeing a higher temperature of heat source
than that of materials.
4.The drying machine for sawdust biomass has advantages of reasonable structure, high
efficiency, low energy consumption and convenient for transportation.
Technical Data Of drying machine for sawdust biomass
Model | Inclination (%) | Rotor speed (r/min) | Air inlet temperature (°C) | Power (kw)
| Capacity (t/h) | Weight (t) |
TRM—GTHG0606
| 3-5 | 3-8 | ≤700 | 3 | 0.5-1.5 | 2.9 |
TRM—GTHG1010
| 3-5 | 3-8 | ≤700 | 5.5 | 1.0-3.5 | 5.6 |
TRM—GTHG1512
| 3-5 | 2-6 | ≤800 | 15 | 3.5-9 | 17.8 |
TRM—GTHG1812
| 3-5 | 2-6 | ≤800 | 18 | 5-12 | 25 |
TRM—GTHG2212
| 3-5 | 1.5-6 | ≤800 | 18.5 | 6-15 | 33 |
TRM—GTHG2218
| 3-5 | 1.5-6 | ≤800 | 22 | 10-18 | 53.8 |
TRM—GTHG2220
| 3-5 | 1.5-6 | ≤800 | 30 | 12-20 | 56 |
TRM—GTHG2420
| 3-5 | 1.5-5 | ≤800 | 37 | 18-30 | 60 |
TRM—GTHG3020
| 3-5 | 1.5-5 | ≤800 | 55 | 25-35 | 78 |
TRM—GTHG3025
| 3-5 | 1.5-5 | ≤800 | 75 | 32-40 | 104.9 |
Pictures Show Of drying machine for sawdust biomass
If you are insterested in our machines, pls contact with us without hestation ,and also ple tell us the following question :
1: The capacity you need ?
2: Your raw material ?
We will reply you within 24 hours .
